Image preview - the first page of the document
KC100-TE-AT


>> Download KC100-TE-AT documenatation <<

Text preview - extract from the document
Pos.    Item No.                   Description
001    643700-5    BRUSH HOLDER CAP 7-18
002    191953-5    CARBON BRUSH CB-203
003    159960-4    MOTOR HOUSING COMPL.
004    KC903483    TAPPING SCREW 5x40
005    851457-6    NAME PLATE
006    266119-7    TAPPING SCREW FLANGE 4x25
007    415439-8    SWITCH LEVER
008    651923-1    SWITCH TG70B
009    231230-4    COMPRESSION SPRING 4
010    415440-3    LOCK-OFF BUTTON
011    KC903859    POWER SUPPLY CORD
012    682504-0    CORD GUARD 10-85
013    687063-9    STRAIN RELIEF
014    266121-0    TAPPING SCREW 4x18
015    645200-1    NOISE SUPPRESSOR
016    415431-4    HANDLE COVER
017    211056-0    BALL BEARING 629LLB
018    681633-6    INSULATION WASHER
019    516578-8    ARMATURE ASS'Y 230V
020    636203-6    FIELD
021    266109-0    TAPPING SCREW FLANGE 5x65
022    415436-4    BAFFLE PLATE
023    241868-7    FAN 82
024    211201-7    BALL BEARING 6002LLB
025    KC903481    WASHER
026    KC903284    HEX NUT
027    KC903305    SPRING RING A12
028    211301-3    BALL BEARING 6004LLB
029    KC903296    STOP RING
030    KC903297    SHAFT WASHER 22x42x7
031    KC903449    SPINDLE
032    KC903306    PIN M6x10
033    212104-8    NEEDLE BEARING TLA1212
034    KC903290    KNOB
035    KC903208    DEPTH GUIDE
036    KC903288    Ring 14X25X12
037    KC903306    PIN 6x10
038    KC903252    SCREW
039    KC903256    WASHER 25X44X4
040    KC903257    PLANE BEARING
041    KC903307    WASHER A10,5
042    KC900582    HEX. NUT M10
043    KC903292    SIDE GRIP
044    KC903454    CASING CPL.
045    KC903251    MAIN POLE
046    KC903255    SPRING
047    KC903304    SET BOLT M6x35
048    KC903291    LEVER
049    KC607860    ADJUSTING SPRING
050    KC200578    WASHER 6,4
051    KC705536    PRESSURE PLATE
052    265442-7    HEX. BOLT M8x40
053    931403-6    HEX. NUT M8
054 KC705537 TRIPPING PIECE
055 931602-0 HEX. NUT M12
056 KC903303 O RING
057 KC903485 COWLING
058 KC903298 SCREW
059 KC773522 GROOVED PIN 2x8
060 KC903284 HEX. NUT M12
061 KC900584 O RING 5x2,5
062 265251-4 HEX. BOLT M6X16
063 KC903450 COVER
064
065 KC620107 HANDLE

                                                 Kc100_pl.xls
066 KC773050 HEX. NUT M18x1,5
067 KC705489 GUIDE
068 KC705490 PIN GUIDE
069 KC771137 SET BOLT
070 KC607819 CLAMPING
071 KC607817 TENSION SCREW
072 KC607811 GUIDE CPL.
073 KC903210 BASE
074 781003-0 WRENCH 10
075 781006-4 WRENCH 13
076 781027-6 WRENCH 19
077 783204-6 HEX. WRENCH 6


A   P-22078   MORTISING CHAIN 30MM
A   P-22084   MORTISING CHAIN 40MM
A   P-22090   MORTISING CHAIN 50MM
A   P-22109   BAR 30MM
A   P-22115   BAR 40MM
A   P-22121   BAR 50MM
A   P-22137   CHAIN WHEEL 30MM
A   P-22143   CHAIN WHEEL 40MM
A   P-22159   CHAIN WHEEL 50MM
                                     A = Accessories




                                                       Kc100_pl.xls
