Image preview - the first page of the document
KP301-TE-AT


>> Download KP301-TE-AT documenatation <<

Text preview - extract from the document
Pos.   Item No.   Description
001    H311201    BELT COVER
002    H311202    HOLDER
003    H311203    MULTI V BELT
004    H311204    HEX. NUT
005    H311205    TOOTHED BELT PULLEY BIG
006    H311206    TOOTHED BELT PULLEY LITTLE
007    H311207    CHEESE HEAD SCREW SPECIAL
008    H311208    END SHIELD
009    211206-7   BALL BEARING 6202LLB
010    H311210    SEALINGRING SPECIAL
011    H311211    COVER
012    211201-7   BALL BEARING 6002LLB
013    H311213    CIRCLIP 32
014    H311214    CUTTER SHAFT
015    H311215    CLAMPING RAIL SET
016    H311216    CLAMPING BAR
017    P-19825    PLANER BLADE STANDERD
       P-19831    PLANER BLADE
018    H311218    HEX. SCREW SPECIAL
019    H311219    TURNING GRIP
020    H311220    SPINDLE BEARING
021    H311221    SPINDLE
022    H311222    GUID ROD
023    H311223    SLIDE
024    H311224    CARRIER
025    H311225    CHIP DEFLECTOR
026    H311226    BASE PLATE
027    H311227    GRIP
028    H311228    STAR KNOB
029    H311229    STOB ROLLER
030    H311230    SUPPORTING WASHER
031    H321231    BALL BEARING 6001RS
032    H311232    END SHIELD
033    H311233    END COVER
034    H311234    MOTOR BEARING SHIELD
035    H311235    RING
036    H311236    CARBON BRUSH SET
037    H311237    BRUSH HOLDER CUP
038    H311238    MOTOR HOUSING
039    H311239    STATOR
040    H311240    AIR DEFLECTOR
041    H321231    BALL BEARING 6001RS
042    H311242    ARMATURE ASS'Y
043    H311243    POWER SUPPLY CORD WITH PLUG
044    H311244    CORD GUARD
045    H311245    GRIP
046    H311246    PROTECTIVE SWITCH
047    H311247    SWITCH
048    H311248    CAPACITOR
049    H311249    PLUG
050    781213-9   WRENCH 8
