Image preview - the first page of the document
LS0714FL-TE


>> Download LS0714FL-TE documenatation <<

Text preview - extract from the document
T    ECHNICAL INFORMATION
    Models No.               LS0714, LS0714F, LS0714FL, LS0714L
                                                                                                                      PRODUCT
                                                                                                                           P 1 / 28

    Description              Slide Compound Saw 190mm (7-1/2")

CONCEPT AND MAIN APPLICATIONS
   New slide compound saw model LS0714 has been developed to
   improve cost-effectiveness by removing electronic circuit for soft start &
   constant speed from model LS0713.
   The primary use is for making/modifying interior decorations in apartment
   building. Model LS0714's compact design and light weight are
   convenient to carry to workplace.

   The LS0714 series is available in the following variations:
   *LS0714: With neither Fluorescent job light nor Laser marker
   *LS0714F: With Fluorescent job light for cutting workpiece in dark places
   *LS0714FL: With Fluorescent job light and Laser marker for easy trace of
               cutting line                                                                      Dimensions : mm ( " )
   *LS0714L: With Laser marker                                                                Length ( L )  670 (26-3/8)
   < Note >                                                                                   Width ( W )     430 (17)
   LS0714F, LS0714FL and LS0714L are not supplied to Canada.                                  Height ( H )    458 (18)

 Specification
                                                                           Continuous Rating (W)
      Voltage (V)           Current (A)           Cycle (Hz)                                                Max. Output(W)
                                                                         Input             Output
         110                      9.7              50 / 60               1,010              450                   1,200
         120                     10.0              50 / 60                                  500                   1,200
         220                      4.8              50 / 60               1,010              450                   1,200
         230                      4.6              50 / 60               1,010              450                   1,200
         240                      4.4              50 / 60               1,010              450                   1,200

    Model No.                                          LS0714              LS0714F            LS0714FL            LS0714L
                  Diameter: mm ( " )                                               190 (7-1/2)
    Saw blade     Hole diameter: mm ( " )                                           20 (13/16)
    No load speed: min-1= rpm.                                                        6,000
    Fluorescent job light                                 No                 Yes                 Yes                 No
    Laser marker                                          No                  No                 Yes                 Yes
    Lock-off botton for trigger switch                                                 Yes
                                                                                        No
    Electric brake
                                                                           (LS0714 for Canada: Yes)
    Protection against electric shock                                           Double insulation
    Power supply            Australia                                               2.0 (6.6)
    cord: m ( ft )          Except Australia                                        2.5 (8.2)
    Net weight: kg ( lbs )                            12.5 (27.6)         12.8 (28.2)         13.1 (28.9)         12.8 (28.2)
   Cutting capacity: mm ( " )
                                    Bevel angle          45
