Image preview - the first page of the document
LS1030-TE


>> Download LS1030-TE documenatation <<

Text preview - extract from the document
T     ECHNICAL INFORMATION
   Models No.                      LS1030
                                                                                                                          PRODUCT
                                                                                                                            P1/2

   Description                     255mm ( 10" ) Miter Saw
CONCEPTION AND MAIN APPLICATIONS
   The above product has been developed as a light weight version
   of the existing model LS1020.
                                                                    H                                                          W
   Its brief benefits and features are
   * Possible to cut 2 x 4 and 4 x 4 wooden materials without
     help of wood facing.
   * Much lighter than the existing model LS1020 in weight.
      LS1030 : 10. 8 Kg                                                                                         L
      LS1020 : 18. 5 Kg
   * Possible to connect vacuum cleaner for dust free cutting work.                                   Dimensions : mm ( " )
                                                                                                 Length ( L ) 470 (18-1/2)
                                                                                                 Height ( H ) 510 (20)
 Specification                                                                                   Width ( W ) 485 (19-1/8)

                                                                                    Continuous Rating (W)
      Voltage (V)                Current (A)                   Cycle (Hz)                                        Max. Output(W)
                                                                                   Input           Output
           115                       12                         50 / 60            1,380            750                1,800
           200                        7                         50 / 60            1,380            750                1,800
           220                        6.5                       50 / 60            1,380            750                1,800
           230                        6                         50 / 60            1,380            750                1,800
           240                        6                         50 / 60            1,380            750                1,800
                  Diameter : mm (")                  255 (10) - 260 (10-1/4)
   Blade
                  Arbor : mm (")                    25, 25.4 (1), 15.88 (5/8),
   No load speed (min-1 = rpm)                                  4,600
   Protection from electric shock                      by double insulation
   Electric brake                                                Yes
   Lock off switch                                               Yes
   Cord length : m (ft)                                    5 (16.4)
   Net weight : Kg (lbs) without holder ass'y              10.6 (23.4)
                  Capacity with 255mm (10") saw blade : mm (")
                              0
