Image preview - the first page of the document
ML180-TE


>> Download ML180-TE documenatation <<

Text preview - extract from the document
T        ECHNICAL INFORMATION                                                                  New Tool

          For Models           ML180                                            324 mm
          Description          Rechargeable Torch                              (12-3/4")




CONCEPTION AND MAIN APPLICATIONS                                                                121 mm
                                                                                                (4-3/4")
Model ML180 is the sister version of the existing Model ML120 and
ML140.
                                                                                     95
Model ML180 is powered by 18V Batteries, which are Battery 1822                    (3- mm
                                                                                      3/4
and 1833.                                                                                 ")


   Specifications
                                                                           ML180
      Voltage                                                              DC18V
      Current                                                              0.6A
      Net. Weight (Without Battery)                                        0.29kg(0.631bs)
      Continious lighting                                 2.0Ah Battery    180min.
      time                                                2.2Ah Battery    200min.
      Bulb                                                                 18V, 0.6A
      Bulb life                                                            50hr or more


    Standard     equipment
     Strap...1
     Bulb...2(1:on tool, 1:for replacement)
       (Note) The standard equipment may differ from country to country.


    Optional     accesories
     Bulb set
     Battery 1822(Ni-Cd)
     Battery 1833(Ni-MH)
     Battery Charger DC1801


    Features     and benefits
     See the sheets attached for more information.
ML180

                                                                                          Battery 1822 or 1833
                                                                                          Battery is not included in Standard Equipment
 Angle Adjustable Torch Head is common to ML120/ML140

                                                              Push-Botton Switch




                                                      Rib for holding tool comfortably


                             Spare Bulb is stored in Head




          Four positive stop position at 0 , 45 , 90 ,110


                                                                         Compact and stable design
                                                                         Thanks to supports mounted on the back of Rechargeable Torch,
                                                                         it can be kept stable in a horizontal position
                                                                         as well as vertical position.
Wiring   diagram                       Switch
                                                                     Unit R
                    Orange                              Orange



                   T-


                   T+



                                                                     Unit L
                               Black




Wiring                                                           Case With Unit R




                             Orange        Switch



                                           Black




                                            When installing Caase axis unit in Housing L saide,
                                             be sure to put Case axis unit R
                                            (Orange lead wire side) in upper position.
