Image preview - the first page of the document
ML700-TE


>> Download ML700-TE documenatation <<

Text preview - extract from the document
T   ECHNICAL INFORMATION
      Models No.                  ML700
                                                                                                            New Tool


      Description                 Makita Rechargeable torch                               Hanging code

CONCEPTION AND MAIN APPLICATIONS                                          Red filter
  Makita battery 7000 is used in this portable light and 7.2 V
  battery specification common with battery for model 6010D,                                                   70mm
  6012D, 6710D, 9200D, and 9500D.
  This product is available independently. The product also is sold
  in set with 6010DW in such event as Christmas sales. Also is
  sold combination with 6010DW, 6012DW, and 6012DL                    67mm
                                                                                          268mm


  Specifications

         Voltage (V)                  Current (A)
      7.2, (Battery 7000)               0.55




   Function
           Continuous lighting time: 110 minute after full charging
           Service life of bulb: More than 30 hours
           Intensity of illumination: More than 2,000 lux at the center of within 20mm diameter 1 meter away
      from light source
   Weight (kg): 0.2



  Standard equipment
   Red color filter ....................1
   Hanging code .................... 1
   Bulb (Spare parts) ............. 1
                                                    Refer to figure                Figure 1

  Optional accessories
   Makita battery 7000                                                             Flat



  Features and benefits
   (1) Lamp head angle can be changed in three steps.
   (2) Light can be put in upright position on flat stand.
   (3) Service life of bulb has two times longer comparing with common bulb used for dry cell type flashlight.
   (4) Convenient hanging code is provided to carry and storage.
   (5) Red filter is attached for emergency alarming use.
   (6) Stabled brightness is maintained during lamp lighting without gradually fading away the brightness like dry
       cell battery type because Ni-Cd alkaline battery is used.



   The standard equipment for the tools shown may differ form country to country.
Repairing
1. Removing and installing lamp head
   (1) Removing method
       Make lamp head at angle       position [Refer to Figure 1]
       and pull lamp head and power source case toward right and
       left respectively then lamp head can be removed from
       power source case.
   (2) Mounting method
       Insert lamp head into power source case pushing black
       projection at the head of the case into groove at lamp head.
       Relative position between lamp head and power source
       case at mounting is equivalent to angle     position.




                                                      This groove has no relation for mounting


                                                       This groove is used for mounting




                                                    Projection




                                         Figure 2




2. Tightening torque for screw
   (1) This unit is assembled using tapping screw. Do not fasten
       screw overly more than required torque because female
       screw will be broken. [Tightening torque is 5kg-cm]
