Image preview - the first page of the document
>> Download MT060-TE documenatation <<
Text preview - extract from the document
T ECHNICAL INFORMATION
Model No. MT060 / MT061
PRODUCT
P1/8
Description Cordless driver drills 9.6V / 12V L
CONCEPT AND MAIN APPLICATIONS
The above products have been added to our MAKTEC series model
as a cordless tool. Their brief benefits and features are;
* Less expensive, but service life is long as the existing model.
* Easy to repair construction H
Listed below are variations of MT060 and MT061
Model No. Items included as a set
MT060SK Ni-Cd Battery 9050 x 1 pc Charger DC1250 W
MT060SK2 Ni-Cd Battery 9050 x 2 pcs. Charger DC1250 Dimensions : mm ( " )
MT061SK Ni-Cd Battery 1250 x 1 pc Charger DC1250 Model No. MT060 MT061
Length ( L ) 190 (7-1/2)
MT061SK2 Ni-Cd Battery 1250 x 2 pcs. Charger DC1250
Height ( H ) 238 (9-3/8)
Width ( W ) 76 (3) 93 (3-5/8)
Specification
Model No. MT060 MT061
Voltage ( V ) 9.6 12
No load speed : (min -1= rpm) 0 - 700
Keyless drill chuck Yes
Chuck ability : mm ( " ) 0.8 - 10 (1/32 - 3/8)
in Steel : mm ( " ) 10 (3/8)
Capacities in Wood : mm ( " ) 15 (5/8)
Screw : mm ( " ) 5.1 x 35 (3/16 x 1-3/8)
Hard joint 13 15
N.m
Soft joint 8 9
Max. fastening Kgf.cm Hard joint 133 153
torque Soft joint 82 92
Hard joint 115 133
in lbs Soft joint 71 80
Reverse switch Yes
Electric brake Yes
Torque adjustment 5 Stages + Drill mode
Net weight :Kg (lbs ) 1.3 (2.9) 1.4 (3.1)
Standard equipment
* Battery cover ................................ 1 pc. (for MT060SK and MT061SK)
* Battery cover ................................ 2 pcs. (for MT060SK2 and MT061SK2)
* Plastic carrying case ..................... 1 pc.
< Note > The standard equipment for the tool shown may differ from country to country.
Optional accessories
* Battery 9050 for MT060SK and MT060SK2
* Battery 1250 for MT061SK and MT061SK2
* Charger DC1250
P2/8
Features and benefits
MT060 MT061
Adjustable torque
Keyless drill chuck in 5 stages + drill mode
for quick and easy
changing of bits
Distinctive orange color
for MAKTEC series model
Switch trigger for
variable speed control
Push button type
reverse switch Body is assembled with machine
screws for easy repairing.
For MT061 For MT060
Newly developed MAKTEC type Newly developed MAKTEC type
12 V Ni-Cd battery 1250 9.6 V Ni-Cd battery 9050
Comparison of products
Model No. MAKTEC MAKITA MAKTEC MAKITA
Specifications MT060 6222D MT061 6223D
Voltage : V 9.6 9.6 12 12
Chuck ability 10 10 10 10
in Hard joint : N.m 13 15
(Kgf.cm) (133) (153)
Max.
fastening in Soft joint : N.m 8 9
torque (Kgf.cm) (82) (92)
in old measurement : N.m 8 10
(Kgf.cm) (82) (102)
in Steel : mm ( " ) 10 (3/8) 10 (3/8) 10 (3/8) 10 (3/8)
Capacity
in Wood : mm ( " ) 15 (5/8) 15 (5/8) 15 (5/8) 15 (5/8)
No load speed : (min -1= rpm) 0 - 700 0 - 700 0 - 700 0 - 700
Torque adjustment in driver mode 5 stages 5 stages 5 stages 5 stages
Length : mm 190 202 190 202
Dimensions
(") (7-1/2) (8) (7-1/2) (8)
Height : mm 238 221 238 221
(") (9-3/8) (8-3/4) (9-3/8) (8-3/4)
Width : mm 76 77 93 94
(") (3) (3) (3-5/8) (3-11/16)
Net weight : Kg (lbs) 1.3 1.4 1.4 1.5
(inclusing battery) (2.9) (3.1) (3.1) (3.3)
Features and benefits P3/8
Charger DC1250 Battery 9050 Battery 1250
Charging light
The red charging light will keep
Newly developed lighting up steadily during charge.
MAKTEC type batteries With finish of charge it will be off.
Distinctive orange color
Battery 9050 Battery 1250 for MAKTEC series model
9.6V / 1.3 Ah 12V / 1.3 Ah Charger DC1250
Interchangeability
Battery for MAKTEC Battery for MAKTEC
series models series models
Charger for the existing Charger for MAKTEC
MAKITA models series models
Battery for the existing Battery for the existing
MAKITA models MAKITA models
Batteries which can be charged
with DC1250, and charging time
Voltage
Battery type Charging time 9.6V 12V
MAKTEC * approx. 60 min. 9050 1250
9000 1200
Ni-Cd 1.3Ah
MAKITA approx. 60 min. 9100 1200A
9120 1220
< Note >
* approx. 60 min. : The charging time for MAKTEC batteries
may be longer than 60min., in case of
variable input voltage.
Comparison of products
Model No. MAKTEC MAKITA
Specifications DC1250 DC1470
Output voltage 9.6 - 12 7.2 - 14.4
Charging time for 1.3Ah battery approx. 60 min. approx. 60 min.
Dimensions 169(6-5/8) x 86(3-3/8) 145(5-3/4) x 80(3-1/8)
(L x W x H) : mm ( " ) x 75(2-15/16) x 63(2-1/2)
Weight : Kg (lbs) 1.1 (2.43) 0.41 (0.90)
Repair P4/8
< 1 > Removing drill chuck
( 1 ) After removing battery from the machine, unscrew pan head screw M5x22 by turning clockwise. See Fig. 1.
Employ impact driver, if it is difficult to unscrew with your hand.
Pan head
screw M5x22
Open the jaws of drill chuck
fully, and then, unscrew
pan head screw M5x22.
Fig. 1
( 2 ) Insert hex wrench into drill chuck, and grip the hex wrench with drill chuck firmly.
Set the machine in the drill mode and push change lever (reverse switch button) for clockwise rotation. See Fig. 2.
Holding the machine on the working table firmly, turn drill chuck clockwise by striking the inserted hex wrench
with plastic hammer. See Fig. 2A. Then, drill chuck can be removed from the machine.
Set in the drill mode by
turning adjust ring.
Push change lever for
clockwise rotation.
Fig. 2A
Fig. 2
< 2 > Disassembling gear assembly and DC motor
( 1 ) After removing drill chuck as illustrated in Fig. 1, Fig. 2 and Fig. 2A, separate housing L from housing R, by
unscrewing 8 pcs. of pan head screws M5x22. See Fig. 3.
Housing L
Housing R
Fig. 3
Repair P5/8
( 2 ) Separate gear assembly and Dc motor from housing R at a time . See Fig. 4.
Gear assembly can be separated from DC motor. See Fig. 4A.
Gear assembly
Gear assembly
Dc motor from Dc motor from
Fig. 4
Housing R Housing R
Fig. 4A
< 3 > Assembling the inner parts to housing
(1) Mount gear assembly to DC motor. See Fig. 4A. Assemble gear assembly and DC motor to housing R in a unit.
with paying attention to < Note 1 > and < Note 2 >. See Fig. 5.
< Note 2 >
Marking Align this convex portion
< Note 1 > (red) with the concave on housing R.
Bringing (-) terminal of
DC motor to the switch side,
align the concave portion
of red marking side, with
the convex on housing R. (+)
(-)
Housing R Housing R
Fig. 5
(2) Assemble housing L to the housing R by
fastening with 8 pcs. of pan head screws M3x22.
see Fig. 6.
< Note >
The fastening torque of pan head Housing L
screws M3x22 is 0.39N.m - 0.78N.m
(4.0Kgf.cm - 8.0Kgf.cm.)
Housing R
Fig. 6
Repair P6/8
< 4 > Assembling drill chuck
(1) Temporally mount drill chuck to spindle portion of gear assembly by screwing it to the neck of spindle.
And then, grip hex wrench with the drill chuck firmly. See Fig. 7.
Fig. 7
(2) Set the machine in the drill mode and push change lever (reverse switch button) for clockwise rotation.
Hold the hex wrench with vise. See Fig. 8
Set in the drill mode by
turning adjust ring.
Push change lever for
clockwise rotation.
Fig. 8
(3) Attach the fully charged battery to the machine. And holding the machine with your hand firmly, rotate
the machine with the highest speed for approx. 1 second to fasten drill chuck to the spindle firmly.
See Fig. 9.
(4) Screw pan head screw M5x22 anti-clockwise. See Fig. 10.
Pan head
screw M5x22
Fig. 10
Fully charged
battery
Fig. 9
Circuit diagram P7/8
Color index of lead wires
Black
Red
DC Motor
M1 M2
Switch
Battery
holder
Wiring diagram
Connect the lead wires (red) and (black)
to DC motor from the housing R side.
See Fig. 11.
Housing R
side
Housing L
side
Lead wire (red)
Marking
(red)
Lead wire (black)
DC Motor
Fig. 11
Wiring diagram P8/8
Put DC motor into housing R with referring to
"< 3 > Assembling the inner parts to housing"
at page 5.
Lead wire
(red)
Lead wire
(black)
Fix the lead wires for connecting
DC motor with switch, with lead
holder.
The lead wires for connecting
to switch have to be connected
as per the illustration.
