Image preview - the first page of the document
MT064-TE


>> Download MT064-TE documenatation <<

Text preview - extract from the document
T     ECHNICAL INFORMATION
   Models No.                  MT064, MT065                                                                            L
                                                                                                                           PRODUCT
                                                                                                                             P1/9

   Description                 Cordless Driver Drill 14.4V / 18V

CONCEPTION AND MAIN APPLICATIONS                                                                    H
   The above products have been added to MAKTEC series.
                                                                                                           MT064
   Their brief benefits and features are;
   * 2 speed and variable speed control
   * Less expensive, but service life is long as the existing model.                                                             W
   * Easy to repair construction
                                                                                                                      L
   Listed below are variations of MT064 and MT065
      Model No.                  Items included as a set
     MT064SK        Ni-Cd Battery 1450 x 1 pc.
                                                       Charger                                       H
     MT064SK2 Ni-Cd Battery 1450 x 2 pcs.                                                                  MT065
                                                       DC1850
     MT065SK        Ni-Cd Battery 1850 x 1 pc.
     MT065SK2 Ni-Cd Battery 1850 x 2 pcs.
                                                                                                                                 W

                                                                                                       Dimensions : mm     (")
                                                                                              Model No.      MT064           MT065
                                                                                              Length ( L ) 214 (8-3/8)     225 (8-7/8)
                                                                                              Height ( H ) 249 (9-3/4)     255 (10)
                                                                                              Width ( W ) 94 (3-11/16)     95 (3-3/4)
   Specification
   Model No.                                                MT064                                     MT065
   Voltage ( V )                                              14.4                                       18
   No load speed                 High                      0 - 1300                                  0 - 1300
              : (min -1 = rpm)
                                 Low                        0 - 400                                   0 - 400
   Keyless chuck                                              Yes                                       Yes
   Chuck ability : mm ( " )                          0.8 - 10 (1/32 - 3/8)                     2.0 - 13 (1/16 - 1/2)
                   in Steel : mm ( " )                      10 (3/8)                                  13 (1/2)
   Capacities      in Wood : mm ( " )                        25 (1)                                 28 (1-1/8)
                   Screw : mm ( " )                6.0 x 75 (1/4 x 2-15/16)                  6.0 x 75 (1/4 x 2-15/16)
   Max. fastening            Hard joint         28N.m (286 kgf.cm) (248 in.lbs)           30N.m (306 kgf.cm) (266 in.lbs)
   torque                    Soft joint         15N.m (153 kgf.cm) (133 in.lbs)           16N.m (163 kgf.cm) (142 in.lbs)
   Reverse switch                                             Yes                                       Yes
   Electric brake                                             Yes                                       Yes
   Torque adjustment                                19 stages + drill mode                    19 stages + drill mode
   Net weight : kg (lbs)                                   2.0 (4.4)                                 2.2 (4.8)

 Standard equipment
   * Battery cover .................................................................. 1 pc. (For MT064SK and MT065SK)
   * Battery cover .................................................................. 2 pcs. (For MT064SK2 and MT065SK2)
   * Plastic carrying case ...................................................... 1 pc.

   < Note > The standard equipment for the tool shown may differ from country to country.

 Optional      accessories
   * Battery 1450 for MT064
   * Battery 1850 for MT065
   * Charger DC1850
Features    and benefits                                                                                        P2/9
                                          Adjustable torque in
                                          19 stages + drill mode

                                             High / Low
                                             speed change lever                         Keyless drill chuck
     Keyless drill chuck                                                                for quick and easy
     for quick and easy                                                                 changing of bits
     changing of bits                         Push button type
                                              reverse switch




        MT064 14.4V                                                                     MT065 18V


Distinctive orange color                                                            Distinctive orange color
for MAKTEC series model                                                             for MAKTEC series model

                                              Soft grip handle
    Body is assembled                                                                        Body is assembled
                                              pad provides
    with machine screws                                                                      with machine screws
                                              a non-slip surface.
    for easy repairing.                                                                      for easy repairing.
                                            Switch trigger for
   < Note >                                                                                 < Note >
                                            variable speed control
   Tapping screws are used for                                                              Tapping screws are used for
   European countries due to the                                                            European countries due to the
   recycling regulation                                                                     recycling regulation




        For MT064                   < Note >                           For MT065
        Newly developed MAKTEC type Because of this rib,               Newly developed MAKTEC type
        14.4 V Ni-Cd battery 1450   Impossible to attach               18 V Ni-Cd battery 1850
                                    to the existing MAKITA
                                    cordless tools.




                             Interchangeability of battery and charger
                                                             Battery for MAKTEC
                                                             series models
                             Charger for the existing
                             MAKITA models
                                                             Battery for the existing
                                                             MAKITA models


                                                             Battery for MAKTEC
                                                             series models
                             Charger for MAKTEC
                             series models
                                                             Battery for the existing
                                                             MAKITA models
Comparison          of products                                                                                                   P3/9

                          Model No.                   MAKTEC           MAKITA          Competitor A      MAKTEC              Competitor A
  Specifications                                       MT064            6228D             A-14.4          MT065                 A-18
                        Voltage : V                     14.4             14.4             14.4             18                    18
    Battery             Cpacity : Ah                     1.3              1.3              1.3                1.3                 1.3
                        Type of cell                   Ni-Cd             Ni-Cd            Ni-Cd               Ni-Cd             Ni-Cd
  Chuck ability : mm ( " )                             10 (3/8)         10 (3/8)         10 (3/8)          13 (1/2)            10 (3/8)

                          Hard joint : N.m                28               30                20               30                   22
  Max. fastening
  torque :                                                                             ( in catalogu)                        (in catalogue)
                          Soft joint : N.m                15               16                                 16

                         in Steel : mm ( " )           10 (3/8)         10 (3/8)         10 (3/8)          13 (1/2)            10 (3/8)
  Capacity
                         in Wood : mm ( " )             25 (1)         24 (15/16)         25 (1)          28 (1-1/8)          28 (1-1/8)
  No load speed                    High                0 - 1300         0 - 1100         0 - 1250         0 - 1300             0 - 1300
         : (min-1 = rpm)              Low              0 - 400           0 - 350         0 - 350           0 - 400              0 - 450
  Side handle                                            No                No              No                 No                 Yes
  Spindle lock                                           No                No              Yes                No                 Yes
  Soft grip                                              Yes               No              Yes                Yes                Yes
  Torque adjustment (driver mode)                  19 stages            16 stages       5 stages          19 stages           5 stages
                 Length : mm ( " )               214 (8-3/8)           210 (8-1/4)     225 (8-7/8)       225 (8-7/8)         245 (9-5/8)
  Dimensions     Width : mm ( " )                     94 (3-11/16)      94 (3-11/16) 84 (3-5/16)          95 (3-3/4)         84 (3-5/16)
                        Height : mm ( " )        249 (9-3/4)           240 (9-1/2)     248 (9-3/4)        255 (10)             255 (10)
  Net weight : kg (lbs)                               2.0                  1.6             1.8               2.2                  2.0
  (including battery)                                (4.4)                (3.5)           (3.9)             (4.9)                (4.4)

                                                                                     Comparison of working amount
Comparison of working speed                                                          with one fully charged battery 14.4V
        Numbers in chart below are relative values when setting A-14.4 's capacity as 100.
Conditions
* Material: Douglas fir, 25mm in thickness               * Bit size (mm) : Auger bit
