Image preview - the first page of the document
MT240-TE


>> Download MT240-TE documenatation <<

Text preview - extract from the document
T    ECHNICAL INFORMATION
   Models No.                 MT240
                                                                                                                         PRODUCT
                                                                                                                           P1/9

   Description                Portable Cut-Off 355mm (14")

CONCEPTION AND MAIN APPLICATIONS
  The above product has been added to MAKTEC series tool.
  Its features are as follows.                                                                                                  H
  * Less expensive but service life is as long as existing
    MAKITA models.
  * Easy-to-repair construction
                                                      Dimensions : mm ( " )
                                               Length ( L )    500 (19-3/4)
                                               Height ( H )    620 (24-3/8)                 W
                                                                                                                    L
                                                Width ( W )    280 (11)

 Specification
                                                                              Continuous Rating (W)
      Voltage (V)          Current (A)            Cycle (Hz)                                                 Max. Output(W)
                                                                             Input           Output
          110                     15.0             50 / 60                  1,650              900                      2,500
          120                     15.0               60                                        900                      2,500
          220                      9.6             50 / 60                  2,000            1,400                      3,000
          230                      9.2             50 / 60                  2,000            1,400                      3,000
          240                      8.8             50 / 60                  2,000            1,400                      3,000

    No load speed : min-1= rpm.                                     3,800
                       Diameter                                    355 (14)
    Wheel size
           : mm ( " ) Arbor                                        25.4 (1)
                       Thickness                                    3 (1/8)
    Net weight : Kg ( lbs )                          15.9 (35.1) including abrasive cut off wheel
                                                               2.0 (6.6) for Australia
    Cord length : m (ft )
                                                               2.5 (8.2) for other countries
                                                                     Capacity : mm ( " )
                        Miter Angle                            0
