Image preview - the first page of the document
>> Download RP1110C-TE documenatation <<
Text preview - extract from the document
T ECHNICAL INFORMATION
Models No. RP1110C and RP0910
PRODUCT
P1/7
Description 8mm Router (Plunge type) W1
CONCEPTION AND MAIN APPLICATIONS
Model RP1110C and RP0910 are Makita's first 1000W class
professional 8mm plunge routers. Compared with Elu #OF97E,
they are more compact and easier to handle.
Model RP1110C (1100W) with electronic controller and H
Model RP0910 (900W) without electronic controller.
Dimensions for PR1110C
and PR910 : mm ( " )
Width ( W1 ) 269 (10-5/8) W2 L
Width ( W2 ) 150 (5-7/8)
Height ( H ) 260 (10-1/4)
Length ( L ) 110 (4-5/16)
Specification
Current (A) Continuous Rating (W)
Voltage (V) Cycle (Hz) Max. Output(W)
Input Output
RP1110C RP0910 RP1110C RP0910 RP1110C RP0910 RP1110C RP0910
100 12 9.5 50 / 60 1,100 900 710 620 1,500 1,100
110 10 8.6 50 / 60 1,100 900 710 620 1,500 1,100
220 5.3 4.3 50 / 60 1,100 900 710 620 1,500 1,100
230 5.0 4.1 50 / 60 1,100 900 710 620 1,500 1,100
240 4.8 3.9 50 / 60 1,100 900 710 620 1,500 1,100
Model No. RP1110C RP0910
No load speed: (min -1= rpm) 8,000 - 24,000 27,000
Plunge capacity : mm ( " ) 0 - 57 (2-1/4) 0 - 57 (2-1/4)
Collet capacity : mm ( " ) 8 (5/16) or 6.35 (1/4) 8 (5/16) or 6.35 (1/4)
Protection from electric shock Double insulation Double insulation
Cord length : m (ft.) 4.0 (13.1) 4.0 (13.1)
Net weight 3.4 (7.5) 3.3 (7.3)
Standard equipment
Straight guide............. 1 pc.
Wrench 8 ................... 1 pc.
Wrench 17 ................. 1 pc.
Templet guide 12 ....... 1 pc.
Dust nozzle assembly...1 pc.
Nozzle assembly......... 1 pc.
< Note > The standard equipment for the tool shown may be differ from country to country.
Optional accessories
Various router bits,
Collet cone 6,
Collet cone 8,
Collet cone 6.35mm
Hose 28
Features and benefits P2/7
RP1110C and RP0910
With electronic controller: RP1110C (1100W) Compact design for
Without electronic controller: RP0910 (900W) precise routing work
Powerful motor allows use of larger cutter.
Model RP1110C has soft start feature for
smoother start-ups.
Dust nozzle;
Dust collector can be connected
to both upper part and lower part
of motor housing.
Durable cord guard
Dust nozzle Excellent in flexibility to
assembly protect power supply cord
from disconnection
Nozzle assembly Speed control dial (only for PR1110C)
For getting optimal speed
to match the materials.
Switch with lock off / lock on button
Adjusting knob for Lock off button to prevent
fine cutting depth adjustment accidental start
Lock on button for continuous operation
Rigid aluminum bracket
Shaft lock 8mm (5/16") collet cone
for easy bit changing
Comparison of products
with electronic controller without electronic controller
MAKITA Competitor A Competitor B MAKITA Competitor A Competitor B
Model No. RP1110C Model A-1 Model B-1 RP0910 Model A-2 Model B-2
Input (W) 1,100 1,100 900 900 900 720
No Load Speed 10,000
8,000 - 24,000 27,000 24,000 26,500
: rpm.=min-1 - 22,000
Collet capa.(mm) 6 - 8 (1/4" - 5/16")
Plunge capa.(mm) 57(2-1/4") 55 (2-3/16") 55 (2-3/16") 57 (2-1/4") 55(2-3/16") 55 (2-3/16")
Lock-on switch Yes Yes Yes Yes Yes Yes
Lock-off switch Yes Yes No Yes Yes No
Net Weight (kg) 3.4 (7.5lbs) 3.8 (8.4lbs) 2.7 (6.0lbs) 3.3 (7.3lbs) 3.8 (8.4lbs) 2.7 (6.0lbs)
Straight guide Straight guide Straight guide Straight guide Straight guide Straight guide
Standard Templet guide Templet guide Templet guide Templet guide Templet guide Templet guide
Equipment Wrench 17 Wrench Wrench Wrench 17 Wrench Wrench
Wrench 8 Vacuum adapter Wrench 8 Vacuum adapter
Repair P 3/7
< 1 > Repairing armature
(1) Remove router bit, collet nut and stopper pole.
(2) Remove knob (without switch trigger, lock off/on button) by turning it anti-clockwise.
Compression spring 8 is to be removed automatically together with the knob.
Also lock pin has to be taken off from the threaded hole for knob. See Fig.1.
Wing nut M10
Nylon nut M10 50
40
Motor section
Compression spring 8 30
20
10
0
Knob R
Knob
Collet nut
Lock pin
Base section Fig.1
(3) Separate motor section from base section after taking off wing nut M10 and nylon nut M10.
Wing nut M10
Brush holder cap
Nylon nut M10
50
40
30
20
10
0
Motor section
Base section
Fig.2
(4) Take off brush holder cap and carbon brush.
(5) Remove knob cover R by taking off 2 pcs. of tapping screw 4x18.
Pay attention, not to lose compression spring which may spring out from the knob,
when removing the knob cover.
(6) Take off lock off button, trigger and switch from the knob R.
(7) Remove knob R from motor section by taking off pan head screw M6x20
as illustrated in Fig.3.
Compression spring 7 Lock off button
50
Compression spring 8
Carbon brush 40
30
20
10
0 Trigger
Knob cover R
Knob
Brush holder cap
Switch
Pan head
screw M6x20 Tapping screw 4x18
Fig.3
Repair P4/7
(8) Remove retainer cover by taking off 2 pcs.of pan head screw M4x18 as illustrated in Fig.4.
(9) Separate motor bracket section from motor section by taking off 4 pcs. of tapping screw 5x35
as illustrated in Fig.4.
Motor section Armature Tapping screw 5x35
50
40
30
20
10
0
Motor bracket section
Pan head
screw M4x18
Retainer
Retainer cover
Fig.4
(10)Set armature in No.1R039 armature holder, and hold the armature holder with vise
as illustrated in Fig.5. Remove retainer with spanner 32 or monkey wrench from armature shaft
by turning anti-clockwise.
Retainer
1R039 Armature holder for vise : A= 41.5mm
A
1R039 Armature holder
for vise
Vise
Fig.5
(11)Hold motor bracket steadily. Remove the armature by pressing its shaft with arbor press.
Press with arbor press.
Motor bracket
Something to hold bracket
Fig.6
Circuit diagram P5/ 7
Black
Model RP1110C
Black
Black Switch
2 3
Black
Black White
White Terminal
Controller
block
White
Blue
Noise Power supply
White
suppressor cord
< Note > Noise suppressor is not used in some countries.
Model RP0910
Black
Black
Grounding terminal
White
of field
Black
Transparent Switch
sheath
2 3
White Black
White
Terminal
block
Noise
suppressor Power supply
Black cord
< Note > Noise suppressor is not used in some countries.
Wiring diagram A : View from top
P6/7
Model RP1110C Boss Pass lead wire of support (field)and
the same of controller, in the groove.
Pass lead wire of controller
between boss and rib.
Rib
Controller
Boss
A : View from top
Pass lead wire of Put insulated terminal
controller between and slacked lead wires
boss and rib. in this place as per
the illustration.
Sponge
B : View from Sponge for dust protector
knob R side installed in knob R
Lock
Pass lead wires to be connected to off button
switch, as per the illustration.
B : View from knob R side
Switch
Trigger
Wiring in knob R
Terminal block
Fix lead wires to be connected to
terminal block, with lead holder.
And set the lead wires of noise suppressor
inside of the machine (armature side), when
fixing them with lead holder.
Noise suppressor
Cover noise suppressor with sponge
and set its lead wires in side of the
machine (armature side).
Wiring diagram P7/7
A : View from top
Model RP0910 Lead wire of noise suppressor
Boss with transparent sheath
Pass lead wire of noise suppressor
with transparent sheath, between Pass lead wire of support (field)and
boss and rib. the same of noise suppressor with
transparent sheath, in the groove.
Rib
Put insulated terminal
and slacked lead wires
A : View from top Boss in this place as per
the illustration.
Sponge
B : View from Sponge for dust protector
knob R side installed in knob R
Lock
Pass lead wires to be connected to off button
switch, as per the illustration.
B : View from knob R side
Trigger
Wiring in knob R
Fix lead wires to be connected to
terminal block, with lead holder.
And set the lead wires of noise suppressor
Noise inside of the machine (armature side), when
suppressor fixing them with lead holder.
Set noise suppressor as per
the illustrated position.
When noise suppressor without
grounding wire (covered with
transparent sheath) is used,
cover the noise suppressor
with sponge.
