Image preview - the first page of the document
SG150-TE-AT


>> Download SG150-TE-AT documenatation <<

Text preview - extract from the document
                                         Parts List 230V



 Pos.   Item No.               Description                 Price
  1      B47720    BOLT                                      1.00
  2      B03384    WRENCH 13/17                              4.00
  3      B35915    ARMATURE ASS`Y                          215.00
  4     211066-7   BALL BEARING 6200LLB                      4.40
  5      B51003    O-RING 35x2,5                             0.40
         B32615    O-RING 31x2,5                             0.40
  6      B50815    GEAR HOUSING                             81.50
  7      B33415    TAPTITE SCREW M5x20                       0.40
  8      B07450    SCREW 4,8x80                              0.60
  9      B30361    SHIM 0,15                                 1.40
         B30379    SHIM 0,2                                  1.40
         B30387    SHIM 0,3                                  1.40
  13     B30130    BALL BEARING 6003LLU                      8.80
  14     B30015    SLEEVE                                    1.20
  15    211281-3   BALL BAERING 6203LLU                      5.60
  16     B46748    SPINDLE                                  38.20
  17     B30148    O-RING 46x2                               0.70
  18     B11122    HEX. BOLT M8x90                           0.70
  19     B11189    WASHER 8,4                                0.30
  20     B33415    TAPTITE SCREW M5x20                       0.40
  21     B10777    TENSION ROLLER                            4.40
  22     B11247    PIPE                                      3.10
  23     B18952    HEX.NUT M8                                0.40
  24     B33407    HEX.BOLT M8X55                            0.40
  25     B10983    HEX.BOLT M8X16                            4.40
  26     B29934    OUTER FLANGE                              8.80
  27     B30486    RING 3                                    1.90
  28     B10678    RING 10                                   3.10
  29     B30494    RING 18                                   4.40
  30     B50831    SAFETY COVER                             37.10
  31     B11528    HEX. BOLT M8X25                           0.40
  32     B29884    RING 2,7                                  3.10
  33     B30171    BEARING RETAINER                         12.90
  34     B50823    BEARING BOX                              32.40
  35     B21071    WASHER 8                                  0.30
  36     B18952    HEX.NUT M8                                0.40
  38     B41418    BAFFLE PLATE                              4.40
  39     B36137    SCREW 4X80                                0.60
  40     B50849    FIELD ASS`Y                              81.50
  41     B08482    SIDE GRIP                                14.00
  42     B21030    PAN HEAD SCREW 3,9X13                     0.30
  43     B38299    BRUSH HOLDER COVER                        0.85
  44     B32508    BRUSH HOLDER                              6.45
  45     B45872    CARBON BRUSH                              5.60


6HLWH  YRQ
                                     Parts List 230V


  46    B47721    NAME PLATE                            1.90
  47    B50807    MOTOR HOUSING                        37.10
  48    B31096    PIPE                                  4.40
  49    B09506    TENSION ROLLER                        3.10
  50    B26948    WASHER 13                             0.40
  51    B30981    HEX. BOLT M7X12                       0.60
  52    B31070    WASHER 7,4                            0.30
  53    B10801    HOLDER                               25.40
  54    B48611    HANDLE SET                           25.40
  55    B14886    NOISE SUPPRESSOR                      3.10
  56    B25221    CORD GUARD                            0.60
  57    P-12918   POWER SUPPLY CORD 1.50-2-5M          10.70
  58    B17913    STRAIN RELIEF                         1.40
  59    B20990    PAN HEAD SCREW 3,9X16                 0.30
  60    B31468    SWITCH                               28.20
  61    B44941    PAN HEAD SCREW 4,8X38                 0.40
  62    B42721    PAN HEAD SCREW 3,9X19                 0.30
  63    B35055    CONTROLLER                           56.20

A001    B50856    MULTI STEEL CASE                     33.00
A002    P-22327   DIAMOND WHEEL F. ABRASIVE            75.00
A003    P-22311   DIAMOND WHEEL F. HARD MATERIAL       86.00




6HLWH  YRQ
