Image preview - the first page of the document
T221D-TE


>> Download T221D-TE documenatation <<

Text preview - extract from the document
T    ECHNICAL INFORMATION                                                                                  New Tool


       Models No.                T221D/DW
       Description               10mm(3/8")Cordless Stapler

CONCEPTION AND MAIN APPLICATIONS                                                        199mm(7-7/8")

Model T221D/DW is a battery 9100 version of the existing
Model T220D/DW. It accepts Arrow Staples. Model T221D is




                                                                        193mm(7-5/8")
sold with a battery cartridge 9100 but without a fast charger.
Model T221DW includes a battery cartridge 9100 and a fast
charger DC9700.


                                                                                                           58mm(2-1/4")

                                                                                        52mm(2-1/16")
   Specifications
    DC Magnet Motor (9.6V)
    Hammer Stroke       44mm (1-3/4")
                Width   10mm (3/8")
    Applicable
    Staple      Length 10mm (3/8"), 13mm (1/2"), 16mm (5/8") for both soft and hard materials
                        19mm (3/4"), 22mm (7/8") for soft material only
    Magazine Capacity   100pcs.of staples
    Net Weight          1.7kg (3.7lbs)


   Standard equipment
    Battery Cartridge 9100, Fast Charger DC9700 (T221Dw only), Plastic Carrying case (T221DW only)


   Optional accessories
    Staple 1010, 1013, 1016, 1019, 1022 (5,000 pcs. in box), Battery Cartridge 9100, Fast Charger DC9700


   Features and benefits
   1.Accepts Arrow Staples.
   2.Compact, lightweight but efficient and powerful stapler thanks to spring-loaded double crank mechanism
   3.Shoots approx. 750 staples on a single battery charge.
   4.See the attached sheet for more information.




The standard equipment for the tools shown may differ from country to country.
                                                          Convenient handstrap for hanging
                                                          stapler from your wrist
                            Shoots staples the moment you
                            switch ON




                                                                             Sub-magazine can be removed from
                                                                             stapler just by removing one screw

Safety lever to prevent accidental
discharge                                              "Peep" window to see how many
                                                       staples remain in magazine

                          Adjustable stapling depth just by
                          turning the nut (knob
