Image preview - the first page of the document
>> Download UB1101-TE documenatation <<
Text preview - extract from the document
T ECHNICAL INFORMATION
Models No. UB1100, UB1101
PRODUCT
P1/4
Description Blower
W
CONCEPTION AND MAIN APPLICATIONS L
The above models are economical versions of our existing
Models 4014N and 4014NV, and feature the ergonomic
designed, new handle for more comfortable and controlled
operation. H
UB1101 features variable speed control switch
while UB1100 is a single speed blower.
Dimensions : mm ( " )
Length ( L ) 480 (18-7/8)
Width ( W ) 170 (6-11/16)
Height ( H ) 180 (7-1/8)
Specification
Continuous Rating (W)
Voltage (V) Current (A) Cycle (Hz) Max. Output(W)
Input Output
110 5.5 50 / 60 600 350 380
120 5.5 50 / 60 600 350 380
220 2.9 50 / 60 600 350 380
230 2.7 50 / 60 600 350 380
240 2.6 50 / 60 600 350 380
Model No. UB1101 UB1100
Power input ( W ) 600
No load speed : (min -1= rpm) 0 -16,000 16,000
Variable switch Yes No
Lock on switch Yes
Air volume :m3/min. 0-2.8 2.8
Degree of vacuum : kPa (mmH2O) 0 - 5.5 (0 - 560) 5.5 (560)
Air speed : m/s 0 - 51 51
Cord length 5 (16.4)
Net weight :Kg (lbs ) 1.7 (3.7)
Standard equipment
The product for export comes without any accessories.
< Note > The standard equipment for the tool shown may differ from country to country.
Optional accessories
* Dust bag * Flexible hose set
* Long nozzle * Anchor nozzle set
Features and benefits P2/4
Handle of New Design Accessories for Model 4014N/NV can be
for More Comfortable Operation used with UB1100 and UB1101
Ergonomic design allows controlled operation
with less fatigue as illustrated below.
Optimum grip for downward applications
Easy-to-Operate Big trigger
Can be pulled with two fingers
for fatigueless operation.
With variable speed control dial
(UB1101 only)
Grip for fatigueless operation
Also as a Vacuum
Can be used as a vacuum
with an optional dust bag.
Free from
Static Electricity
Prevents the accumulation
of static electricity caused
by dust taken into the
machine.
Comparison of products
Model No. MAKITA Competitor A Competitor B
Specifications UB1101 UB1100 4014NV 4014N Mod.A-a Mod.A-b Mod. B-1 Mod.B-2
Continuous Rating Input (W) 600 600 630 460
No load speed : (min -1= rpm) 0 - 16,000 16,000 0 - 16,000 16,000 0 - 16,000 16,000 8,000 - 16,000 16,000
Speed control switch Variable No Variable No Variable No 5 Speed No
Lock on switch Yes Yes Yes Yes Yes Yes Yes Yes
Air volume :m3/min. 0 - 2.8 2.8 0 - 2.8 2.8 0 - 2.8 2.8 1.2 - 2.7 2.7
Suction Blow
Air speed : m/s 0 - 51 51 0 - 51 51
Air volume :m3/min. 0 - 2.8 2.8 0 - 2.8 2.8
Degree of kPa 0 - 5.5 5.5 0 - 5.5 5.5 0 - 5.5 5.5 1.57 - 5.1 5.1
vacuum mmH2O 0 - 560 560 0 - 560 560 0 - 560 560 160 - 520 520
Kg 1.7 1.7 1.7 1.7 1.7 1.7 1.9 1.9
Net weight
lbs 3.7 3.7 3.7 3.7 3.7 3.7 4.2 4.2
Repair P3/4
Assemble fan with meeting the screw hole of the armature shaft with the same of the fan.
And assemble the fan to the armature shaft by screwing pan head screw M4 x 12 as illustrated below.
Fastening torque for
pan head screw M4x12 : 0.69 - 0.98N.m
Pan head screw M4 x 12 (7.0 - 10 kgf.cm)
Screw hole
Fan
Armature shaft Pan head screw M4 x 12
Screw hole
Circuit diagram
Color index of lead wires
Black
White
Power supply cord
M2 Switch
Field 1 2
Shrink these tubes
C1
with heat.
C2
M1
Noise suppressor
Wiring diagram
Field lead wires have to be fixed with lead holders as illustrated in Fig. A.
Lead holder
Shrink these tubes
with heat.
Lead holder
Fig. A
Wiring diagram P4/4
Pass the upper field wire
Ribs between ribs and inner wall.
Pin
Boss
Do not slack the field lead wires
Pass the field lead wires
in the motor housing.
between pin and boss.
