Image preview - the first page of the document
UH3000D-TE


>> Download UH3000D-TE documenatation <<

Text preview - extract from the document
T     ECHNICAL INFORMATION                                                                    New Tool


Models No.             UH3000D
Description            Makita 300 mm Cordless hedge trimmer

CONCEPTION AND MAIN APPLICATIONS
   Cordless light trimmer, which is convenient for working on
    hedges and yards. It can cut twigs up to 8 mm (approximately)                     605
   in diameter, and the power lasts for 20 minutes.
   UH3000DW is a combined model of UH3000D (300 mm
    battery operated hedge trimmer), DC7000 (fast battery 110
   charger), and battery 7000.
   UH3000D doesn't include batteries.




  Specifications
  Direct Current Magnetic Motor RS-550S (6527)
   No Load Speed                           number of strokes: 900/min
   Net Weight                             1.6kg
   Effective blade length                 300mm

  Standard equipment
   grip 32---------1
   blade cover----1


  Optional accessories
   shearing blade assembly, battery 7000


  Features and benefits
   1.Convenient cordless hedge trimmer for working on yards and hedges
   2.Light weight and easy to use for women
   3. Safe lock-off-lever prevents turning on the switch by accident
   4. Great to operate double cranked structure which provides little vibrating
   5. Plastic gear with minimum noise
   6. 1 hour charging provides up to 20 minute operating
   7. Cuts twigs up to 8 mm in diameter
   8. Comes with blade cover for safe storing


  Capacity
   Cutting power (with 1 full charged battery)
     maximum cutting power - approximately 8 mm in diameter
     maximum consecutive operating time - approximately 20 minutes (depends on maintenance)




 The standard equipment for the tools shown may differ form country to country


                                                                                  .
Repair
1. Take out batteries before repairing
2. Attach the housing parts to housing R side when assembling
3. Assemble the plate and the crank on the side the number of helical gear 52 is marked
4. Apply 0.5g of *Molub alloy grease NO.1 thinly on the axis and the teeth of plastic gear
5. Apply 0.5g of *Molub alloy grease NO.1 on outside of the crank, and 0.5g of molydenum disulfide lubricant on
 the connecting surface with shear blade crank
    Note: Applying other grease than indicated or overgreasing may cause grease coming out on the blade and
     increasing friction resistance which will result shortening battery operating time
6. Assemble helical gear 52 and shear blade together to the main body after attaching shear blade and crank
 (Machine won't operate if they're not attached correctly due to shear blade locking)
7. Plug in + side of battery holder to housing R
