Image preview - the first page of the document
UM140D-TE


>> Download UM140D-TE documenatation <<

Text preview - extract from the document
T    ECHNICAL INFORMATION                                                                                  New Tool


Models No.              UM140D

Description             Battery-Powered Grass Trimmer

CONCEPTION AND MAIN APPLICATIONS
   These grass trimmers are operated by Makita battery 121 (lead-acid battery) which can be slung over a shoulder. So
   they are very maneuverable .Model UM140D is sold without battery and charger. Model UM140DW includes a
   Makita battery 121 and a Makita charger DC121.
                                      )
                                    4"
                                    3/
                                 1-
                               (5
                             m
                           m




                                                                24
                        15




                                                                  5m
                      13




                                                                     m
                                                                       (9
                                                                          -5
                                                                           8"/
                                                                             )


                                          16
                                            0m
                                               m(
                                                 6-5
                                                    /16
                                                         ")
                                                                                      Battery 121




  Specifications
   DC Magnet Motor (12 V)
   Effective Cutting Width                             140 mm (5-1/2")
   No Load Speed                                       13,000 R/min.
   Net Weight                                          1.2 kg (2.6 lbs) for tool
                                                       1.9 kg (4.2 lbs) for battery
   Charging Time                                       Approx.8 hours


  Standard equipment
   Blades (10 pcs.), Battery 121 (UM140DW only), Charger DC121 (UMl40DW only)


  Optional accessories
   Blades, Battery 121, Charger DC121


  Features and benefits
   1.Refer to the attached sheet.




 The standard equipment for the tools shown may differ form country to country
                                                            Lock-off button to prevent
                                                            accidental starting



                                                                               Slim handle for easy grippir
                            Large, easy-to-operate switch lever




       Large loop handle for easy
       operation. It can be secured
       to the shaft at desired posision.



                                                                                         Strain relief hook to prevent
                                                                                         battery cord from being acci-
                                                                                         dentally disconnected




                                                               A set of spare blades can be
                                                               kept inside the grip


                                           Powerful motor




                                       Cap allows easy, even cuttiing




Plastic blades with cutting edges
assure smooth cutting

                                                                                     Makita battery 121
                                                                                     (lead-acid battery)
