Image preview - the first page of the document
UM103D-TE


>> Download UM103D-TE documenatation <<

Text preview - extract from the document
T      ECHNICAL INFORMATION                                                                                 New Tool


        Models No.             UM103D
        Description            Battery-Powered Grass Shear

CONCEPTION AND MAIN APPLICATIONS
   These grass shears are operated by Makita battery 121 (lead-acid battery) which can be slung over a shoulder. So
   they are very maneuverable. Model UM103D is sold without battery and charger. Model UMl03DW includes a
   Makita battery 121 and a Makita charger DC121.




                                                                      126mm(5")
  ")
   /16     3
       3-1




                                                        ")
                                                 (10-5/8
         (
           mm




                                          270mm
                                                                                  Battery 121
               97




  Specifications
   DC Magnet Motor (12 V)
   Effective Cutting Width                   100 mm (4")
   Strokes per Minute                        1,000
   Net Weight                                0.75 kg (1.65 lbs) for tool
                                             1.9 kg (4.2 lbs) for battery
   Operating Time                            Approx. 2 hours on a single charge
   Charging Time                             Approx.8 hours


  Standard equipment
   Blade Guard (Blade Cover), Battery 121 (UM103DW only), Charger DC121 (UMl03DW only)


  Optional accessories
   Shear Blade Set, Battery 121, Charger DC121


  Features and benefits
   1.Refer to the attached sheet.




 The standard equipment for the tools shown may differ form country to country
                                                                     Slim handle for easy gripping
                                Lock-off button to prevent acci-
                                denal starting




Blade guard (blade cover) for
safe storage of tool




                                                                                              Hand guard (hand protector) to
                                                                                              protect your hand




                                        Well designed foot for smooth cutting


          Blades can be disassembled for
          easy sharpening




                                                                                Strain relief hook to prevent
                                                                                battery cord from being acci-
                                                                                dentally disconnected


            Makita battery 121(lead-acid battery)
