Image preview - the first page of the document
UT120-TE-AT


>> Download UT120-TE-AT documenatation <<

Text preview - extract from the document
        Pos.       Item No.             Description
         1      EE 7132A240      MOTOR HOUSING COVER
         2      EE 80201267      PAN HEAD SCREW 4,8x45
UT120                               ARMATURE ASS'Y
         3      EE 77316100
         4     210024-0           BALL BEARING 608 2RS
         5      EE 80201333         RETAINING RING 28
         6      EE 80201196        BRUSH HOLDER CPL.
         7      EE 80700013               BRUSH
         8      EE 80201385           WAVE WASHER
         9      EE 80201180           SCREW M4x12
         11     EE 80201305         RETAINING RING 10
         12     EE 83000036           O-RING 22x2,5
         13     EE 80701005          MAGNET SLEEVE
         14    211142-7           BALL BEARING 6001LLB
         15     EE 77318610      CRANK HOUSING COVER
         16     EE 77318400   GEAR HOUSING COMPLETE
         17     EE 74010470           HELICAL GEAR
         18     EE 7731C490               SHAFT
         19     EE 80201252       CONNECTING CORD A
         20     EE 77314187       CONNECTING CORD A
         21    211251-2           BALL BEARING 6003LLB
         22     EE 7731C420              SPINDLE
         24    211256-2           BALL BEARING 6203LLB
         25     EE 7731C430           HELICAL GEAR
         26     EE 80200507            WASHER 17
         30     EE 7132B230              HANDLE
         31     EE 7132B275           COVER PLATE
         32     EE 80601132           CONTROLLER
         33     EE 80900158          MOTOR HOUSING
         34     EE 77316150            FIELD ASS`Y
         35     EE 80201266    PAN HEAD SCREW 3,9x60
         36     EE 7132A140           BAFFLE PLATE
         37     EE 77318590        SIDE HANDLE ASS'Y
         38     EE 80201303         SPRING WASHER 6
         39     EE 80201209     OVAL HEAD SCREW M6x12
         41     EE 80900101        HANDLE COVER CPL.
         42     EE 71323255           CORD GUARD
         43    P-26185            POWER SUPPRY CORD
         44     EE 80201270    PAN HEAD SCREW 4,2x13
         45     EE 71540330           STRAIN RELIEF
         46     EE 80500020          POTENTIOMETER
         47     EE 80600125              SWITCH
         48     EE 80500010            CONDENSER
         49     EE 80201280      PAN HEAD SCREW 4,8x22
         50     EE 80201271      PAN HEAD SCREW 4,2x16
         51     EE 77316186       CONNECTING CORD B
         52     EE 80200582                PIN 4
         53     EE 80201284      PAN HEAD SCREW 4,8x55
         54     EE 77324620              GASKET
