Image preview - the first page of the document
VR250D-TE


>> Download VR250D-TE documenatation <<

Text preview - extract from the document
T    ECHNICAL INFORMATION

Models No.            VR250D
                                                                                                           New Tool



Description           Cordless Vibrating Poker

CONCEPTION AND MAIN APPLICATIONS




                                                                                                                     187mm(7-3/8
   Model VR250D is the first cordless vibrating poker in the                            (40-5/8
                                                                                               ")
   world. Its brief benefits are;                                                 1031mm

     *Easy operation by light weight
     *Anywhere without power source




                                                                                                                                ")
                                                                                                    104m
   Continuous operating time from a single charge is about 20                                           m(4-
                                                                                                             1/8"
                                                                                                                 )
   minutes.

     Motor                  Battery               Fast charger
    VR250DA           Battery 1222 (1 pc.)             No
   VR250DWAE          Battery 1222 (2 pcs.)         DC1410


   Specifications
   Motor                                      DC 12V magnet motor
   Battery                                     Battery 1222 (Ni-Cd,12V,2.0Ah)
   Vibrations per minute                      l3000vpm
   Amptitude                                  1.1 mm(3/64")
   Diameter of vibrator                       25mm(l")
   Length of flexible part                    800mm(31-l/2")
   Net Weight                                 2.9kg(6.4lbs)


   Standard equipment
   Battery Cover ------------------------------------------1 pc.
   Plastic Carrying Case (VR250DWAE only) -------1 pc.
   The standard equipment may differ from country to country.


   Optional accessories
    Battery 1200,1202,1222
    Fast Charger DC1209,DC1410


   Features and benefits
   See the sheet attached for more information.




 The standard equipment for the tools shown may differ form country to country.
Light weight 2.9kg(6.4lbs)
Less fatigue in continuous operation



                                                            Switch with waterproof cover



                                                1")
