Image preview - the first page of the document
Y02611-WW-1


>> Download Y02611-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject              Change of Socket Head Bolt
                                                                                                      Y02611


For Models           RBC220, RBC221, RBC230, RBC250, RBC251, MS220, MS221, MS250, MS251, MS2300,
                     RST250, LT250,
Country              All countries
Description          Socket Head Bolt M5x45 to secure Muffler has been replaced by the one with Washer.
                     Consequently the current Washer 5 (Pt. No. 0031005000) has been eliminated.

                                                    Muffler




                         Current                                                  New

                                   With Adhesive                                         With Adhesive


     Washer M5
    (0031005000)

              Socket Head Bolt M5x45                             Socket Head Bolt M5x45 (with Washer)
                   (0119059650)                                              (0119059600)


Interchangeability(I/C)
 Item No.       Current part                 Q'ty I/C          New part                      Q'ty         Note
          Socket Head Bolt M5x45                       Socket Head Bolt M5x45
See below                                      2   Yes                                        2
          0119059650                                   0119059600                                   Interchangeable
            Washer M5                                                                                    as a set
See below                                      2
            0031005000

Item No. of Socket Head Bolt
Model RBC220 RBC221 RBC230 RBC250 RBC251 RST250 LT250 MS220 MS221 MS2300 MS250 MS251
Item No.  046        064       046            038        046       064       046

Item No. of Flat Washer
 Model RBC220 RBC221 RBC230 RBC250 RBC251 RST250 LT250 MS220 MS221 MS2300 MS250 MS251
 Item No.         045   063      045           037          045     063       045


 Implementation
From July, 1994 production
