Image preview - the first page of the document
Y02935-WW-1


>> Download Y02935-WW-1 documenatation <<

Text preview - extract from the document
T
ECHNICAL INFORMATION
Subject               Change of Pipe Damper (1), Pipe Bracket (1), Pipe Bracket (2)
                                                                                                            Y02935
                                                                                                         (Page 1 of 2)

                      MS220, MS221, MS250, MS251, PE250, RBC220, RBC221, RBC225, RBC226, RBC250,
For Models
                      RBC251, RBC255, RBC256, RBE250
Country               All countries
Description           Pipe Damper (1), Pipe Bracket (1) and Pipe Bracket (2) have been changed as shown below.

                                                                      Pipe Damper (1)




                                                                                               Shaft Pipe
                                                                      Pipe Bracket (1)
                                                                       (6251506602)
                                                                     Pipe Bracket (2)
                                                                      (62151509600)


                            Engine Cover Complete             Pipe Damper (2)
 Pipe Damper (1)

                         Current                                                      New
                    Pipe Damper (1)                                         Pipe Damper (1)
                    (6251506601)                                             (6251506602)


                                       (Cross section)                                              (Cross section)

                                                                           The shape has been changed in this area.

 Pipe Bracket (1)

                         Current                                                      New
                    Pipe Bracket (1)                                        Pipe Bracket (1)
                     (6251506801)                                             (6251509500)
                                                                 Rib has been added for reinforcement.
                          15 mm (9/16")                                                18 mm (11/16")




 Pipe Bracket (2)

                         Current                                                      New
                    Pipe Bracket (2)                                        Pipe Bracket (2)
                     (6251506901)                                            (6251509600)
                             15 mm (9/16")                                               18 mm (11/16")
                                                                                                              Y02935
                                                                                                             (Page 2 of 2)
Interchangeability(I/C)
 Item No.       Current part                     Q'ty I/C         New part                         Q'ty        Note
           Pipe Damper (1)                                Pipe Damper (1)
 See below                                        1                                                 1
           6251506601                                     6251506602
           Pipe Bracket (1)                               Pipe Bracket (1)                                Interchangeable
 See below                                        1    No                                           1
           6251506801                                     6251509500                                           as a set
 See below Pipe Bracket (2)                       1    No
                                                            Pipe Bracket (2)                        1
           6251506901                                       6251509600
Interchangeability mark ;
 The arrow       means that the new part can be substituted for the current.
Note: The current Pipe Brackets (1) and (2) remain available for replacement.
   Item No. of Pipe Damper (1)
  Model MS220 MS221 MS250 MS251 PE250 RBC220 RBC221 RBC225 RBC226 RBC250 RBC251
 Item No.                   073                     083             073       078 073
 Model   RBC255 RBC256 RBE250
Item No.      078       083
  Item No. of Pipe Bracket (1)
Model    MS220        MS221    MS250 MS251         PE250 RBC220 RBC221 RBC225 RBC226 RBC250 RBC251
Item No.                     071                    085       071           076           071

Model    RBC255 RBC256 RBE250
Item No.      076       085
  Item No. of Pipe Bracket (2)
Model    MS220        MS221 MS250 MS251            PE250 RBC220 RBC221 RBC225 RBC226 RBC250 RBC251
Item No.                   072                      086       072           077           072
Model RBC255 RBC256 RBE250
Item No.   077       086

 Note
Instructions when repairing
   When the current parts have been replaced by the new parts, the length of fit of Shaft Pipe to be inserted becomes longer
   by 3 mm as illustrated below. Therefore, always make sure that Shaft Pipe has been inserted to the proper position.
   Insufficient insertion of Shaft Pipe may cause failure and excessive load to main unit of machine; for example, the blade
   does not rotate.
      (For machines using the current parts)                         (For machines using the new parts)
           60 mm                                                        63 mm
          (2-3/8") 15 mm                                               (2-1/2") 18 mm
                     (9/16")                                                     (11/16")




   Shaft Pipe     Shaft
  When re-assembling Control Lever Assembly on the models below, mount the control lever assembly in the position
  as shown below.
      (For machines using the current parts)                     (For machines using the new parts)
                          60 mm                                                    65 mm
                         (2-3/8")                                                 (2-9/16")



(Applicable Models: MS221, MS2201, MS251, MS2501, RBC221, RBC226, RBC251, RBC256, RBC25A,
RBC253, RBE250, PE250)
 Implementation
From July,1996 production
