Image preview - the first page of the document
Y02340-WW-1


>> Download Y02340-WW-1 documenatation <<

Text preview - extract from the document
T
ECHNICAL INFORMATION
Subject              Addition of an Inner Snap Ring to Gear Case Assembly
                                                                                                           Y02340

For Models           MS220, MS221, MS250, MS251, RBC220, RBC221, RBC250, RBC251

Country              All countries
Description          An Inner Snap Ring has been added to Gear Case Assembly, and it is placed between Outer Stop
                     Ring and Shaft as illustrated below. Accordingly, the part number of Gear Case Assembly has
                     been changed. There is a letter of "C" embossed on the new Gear Case as a mark for distinction.
                     At the same time, some constituent parts (written in bold in the following illustration) of Gear Case
                     Assembly have become available.
    New Gear Case Assembly
    Consists of 17 parts as illustrated below, and no modification
    has been implemented except the addition of Inner Snap Ring.
                                     Gear Case
                                                                                    Bolt
                                     embossed "C"
           Ball Bearing 609ZZ
              Outer Snap Ring                                                    Ball Bearing 626

              Inner Snap Ring
              (Newly added)                                                                Ball Bearing 608LLU

                                                                                             Inner Snap Ring

                                                                                                 Receive Washer




                                Gear Set


Interchangeability(I/C)
Item No.       Current part                Q'ty I/C         New part                  Q'ty             Note
           Gear Case Assembly
    003                                     1    Yes Gear Case Assembly                 1
           6253011002                                6253014000
                                                      Inner Snap Ring                   1     A constituent part of
    092
                                                      0031424000                              the new Gear Case Ass'y

    089                                               Gear Set                          1
                                                      6253013000

    090                                               Outer Snap Ring                   1
                                                      0031509000

    091                                               Ball Bearing 609ZZ                1
                                                      6212500300

    093                                               Bolt                              1
                                                      6253011011                              Constituent parts of both
                                                                                              the current Gear Case
    094                                               Ball Bearing 626                  1     Ass'y and the new one
                                                      6213500900
    095                                               Ball Bearing 608LLU               1
                                                      6253503700
                                                      Inner Snap Ring                   1
    096
                                                      0031422000

    097                                               Receive Washer                    1
                                                      6258504400

Implementation
From Apr. 1994
