Image preview - the first page of the document
Y03844-WW-1


>> Download Y03844-WW-1 documenatation <<

Text preview - extract from the document
T
ECHNICAL INFORMATION                                                                                     Y03844
                                                                                                        (Page 1 of 2)

Subject              Changes of Spring Washer Attached to Nut for Securing Blade and/or Gear Case Set/Assembly
For Models           MS20C, MS220, MS2201, MS221, MS2300, MS250, MS2500, MS2501, MS251, MS2600,
                     MS2800, MS2810, MS3100, MS3200, MS3210, MS4150, PE250, RBC201, RBC220, RBC221,
                     RBC225, RBC226, RBC230, RBC25A, RBC250, RBC251, RBC252, RBC253, RBC255, RBC256,
                     RBC260, RBC280, RBC281, RBC310, RBC311, RBC320, RBC321, RBE250, RBK250, RBK410
Country              All countries
Description          Gap of the washer attached to Nut securing a blade has been changed in size to reinforce the spring
                     washer.
                                       Gear Case Assembly/ Gear Case Set




                                                                                              Nut


Note: Parts included in the Gear Case Assembly/Gear Case Set may vary model by model.
Please check item No. on pages 2 of 3 and 3 of 3 for details.

                      Current                                                             New
                       Nut                                                                 Nut
                   (6258505000)                                                        (6258505001)



    9.4 mm                                                         9.8 mm




Interchangeability(I/C)

Item No.         Current part                 Q'ty I/C             New part                     Q'ty        Note
             Nut                                         Nut                                      1
See below                                       1    Yes
             6258505000                                  6258505001
             Gear Case Set                               Gear Case Set
See below                                       1    Yes                                            1
             6023012001                                  6023012002
             Gear Case Assembly                          Gear Case Assembly
See below                                       1    Yes                                          1
             6213017001                                  6213017002
             Gear Case Assembly                          Gear Case Assembly
See below                                       1    Yes                                          1
             6253004000                                  6253004001
             Gear Case Assembly                            Gear Case Assembly
See below                                       1    Yes                                          1
             6253014006                                    6253014007
          Gear Case Assembly                             Gear Case Assembly
See below                                       1    Yes                                          1
          6253021001                                     6253021002
          Gear Case Assembly                             Gear Case Assembly
See below                                       1    Yes                                          1
          6273001005                                     6273001006
                                                                                                                  Y03844
                                                                                                                  (Page 2 of 2)
 Interchangeability(I/C)
  Nut: 6258505001
 Model   MS20C MS220 MS2201 MS221 MS2300 MS250 MS2500 MS2501 MS251                                     MS2600       MS2800
 Item No. F02   005   017    005   038    005   005    017    005                                       038          006

 Model    MS2810 MS3100 MS3200              MS3210      MS4150 PE250           RBC201 RBC220          RBC221        RBC225
 Item No.  005    051    006                 005         068    024             F02    005             005           017

 Model    RBC226 RBC230           RBC25A RBC250 RBC251 RBC252 RBC253 RBC255 RBC256                                 RBC260
 Item No.  017    038               004   005    005    005    005    017    017                                    038

 Model RBC280 RBC281              RBC310 RBC311 RBC320 RBC321 RBE250 RBK250 RBK410
 Item No. 006  005                 051    031    006    005    024     007    068

  Gear Case Set: 6023012002
   Model PE250          RBE250
          005           005
 Item No. INC.          INC.
          004, 006-012, 004,006-012,
          022-024       022-024

  Gear Case Assembly: 6213017002
 Model.  MS2201 MS2500            MS2501     RBC225 RBC226 RBC252               RBC253      RBC255 RBC256 RBK250
         003     003              003        003            003                 003         003           004
         INC.    INC.             INC.       INC.           INC.                INC.        INC.          INC.
 Item No
         004-019 004, 005,        004-019    004-019        004, 005,           004, 005,   004-019       005-020
                 022-033                                    018-029             021-032

  Gear Case Assembly: 6253004001
  Model MS3100          MS4150 RBC310                 RBC311       RBK410
          039           056      039                  016          056
          INC.          INC.     INC.                 INC.         INC.
 Item No. 033-036, 040, 066-068, 033-036, 040,        017-031      066-068,
          043-051       165-175 043-051                            165-175

 Gear case Assembly: 6253014007
 Model    MS220            MS221            MS250            MS251            RBC220           RBC221           RBC250
          003              003              003              003              003              003              003
          INC.             INC.             INC.             INC.             INC.             INC.             INC.
 Item No. 004, 005, 022,   004, 005, 021,   004, 005, 022,   004, 005, 021,   004, 005, 022,   004, 005, 021,   004, 005, 022,
          089-097, 120     089-097, 120     089-097, 120     089-097, 120     089-097, 120     089-097, 120     089-097, 120

 Model    RBC251
          003
          INC.
 Item No. 004, 005, 021,
          089-097, 120

 6253021002
 Model    RBC25A
          002
 Item No. INC.
          003, 004, 018-026
  6273001006
Model MS-2800          MS2810       MS-3200       MS-3210       RBC280        RBC281     RBC320     RBC321
Item No. 002           001          002           001           002           001        002        001
         INC.          INC.         INC.          INC.          INC.          INC.       INC.       INC.
         003-011,      002-010,     003-011       002-010,      003-011,      002-010,   003-011,   2-10, 23-28
         021-026       023-028      021-026       023-028       021-026       023-028    021-026

 Implementation
Since Jan., 2000 production
