Image preview - the first page of the document
Y04416-WW-1


>> Download Y04416-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                Change of Recoilstarter Ass'y
                                                                                                                  Y04416


For Models             G4100R
Country                European countries
Description            Tube has been added to starter rope of recoilstarter ass'y to improve durability.

          Recoilstarer Ass'y




                                                                                        Starter rope

                                                                                               Tube (added)




                                                             85mm
                                                             (3-3/8")




Interchangeability(I/C)

Item No.       Current part               Q'ty I/C        New part                   Q'ty                  Note
           Recoilstarter Ass'y                      Recoilstarter Ass'y
    189                                     1   Yes                                    1
           2705020110                               2705020300

Implementation
Since April, 2004 production
