Image preview - the first page of the document
Y04422-WW-1


>> Download Y04422-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Unification of Muffler Insulator and Muffler Gasket
                                                                                                            Y04422

For Models            PB250, RBL250
Country               All countries

Description           Muffler insulator and Muffler gasket have been unified as illustrated below.


                          Current                                                   New
                                  Muffler gasket                                Muffler gasket (5253500401)
                                  (5233504302)                                  [plays a role of heat insulator.]




      Muffler insulator
       (5253500400)


Interchangeability(I/C)
 Item No.       Current part               Q'ty I/C           New part                   Q'ty             Note
            Muffler insulator                          Muffler Gasket
    063                                      1     Yes                                     1
            5253500400                                 5253500401
            Muffler Gasket
    062                                      1
            5233504302

Implementation
Already implemented since March, 2004 production
