Image preview - the first page of the document
Y04423-WW-1


>> Download Y04423-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Change of Piston
                                                                                                              Y04423

For Models            MS3100, MS3200, MS3200E, MS3201C, MS3201U, MS3210, RBC310, RBC311
                      RBC320, RBC320E, RBC3200, RBC321, RBC3210
Country               All countries
Description           Piston has been modified as illustrated below.
                      This modification decreases operator's effort required for pulling recoil starter lope to start engine.
                      The engine performance remains the same.

                                         Current                                        New
                                                                                        Modified portion




                                         Piston                                       Piston
                                      (5312500600)                                 (5312500601)


Interchangeability(I/C)
 Item No.       Current part                Q'ty I/C         New part                      Q'ty            Note
           Piston                                     Piston
See below.                                   1    Yes                                        1
           5312500600                                 5312500601
Item No. of Piston
 MS3100     MS3200 MS3200E MS3201C MS3201U MS3210                         RBC310       RBC311      RBC320       RBC320E
  078        056     048          056       058                            078          050         056           048

RBC3200      RBC321     RBC3210
  056          058        056


Implementation
Already implemented since April, 2004 production
