Image preview - the first page of the document
Y04496-WW-1


>> Download Y04496-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Change of Spacer Gasket
                                                                                                           Y04496


For Models            EH450, EH490V, EH561, EH620, EH760, HT2045D, HT2049D, HT2062E, HT2256D, HT2276E,
                      MH2556, MS20C, MS2300, MS2600, MS2800, MS2800E, MS2810, MS3200, MS3200E,
                      MS3201C, MS3201U, MS3210, RBC200, RBC201, RBC230, RBC260, RBC261, RBC280,
                      RBC280E, RBC281, RBC320, RBC320E, RBC3200, RBC321, RBC3210, RPT250, RST200
Country               All countries

Description           The thickness of Spacer gasket has been changed from 0.8 mm to 1.0 mm
                      for further enhancement of its airtightness and stabilization of its quality.
                      Also, the color of Spacer gasket has been changed to flesh color from gray.
Interchangeability(I/C)
 Item No.        Current part                  I/C         New part                                  Note
             Spacer Gasket                           Spacer Gasket                     The quantities depend on the
See below.                                     Yes                                     specifications. See below for the
             5103502800                              5103502801
                                                                                       details.

Item No. and destination of the specifications which include only one piece of Space gasket No. 5103502801
EH450 for USA EH561 for USA EH620 for USA EH760 for USA MH2556 MS20C MS2300 MS2600 MS2800
    141           143           137           140        177    043   057    039    050

MS2800E MS2810 MS3200 MS3200E MS3201C for Italy MS3201U for Italy MS3210 RBC200 for Taiwan
  061    049    049     061        049               049           051         068

RBC201 RBC230 RBC260 RBC261 for USA RBC280 RBC280E RBC281 RBC320 RBC320E RBC3200 for Italy
 043    057    039        039        050     061    049    049     061        049

RBC321 RBC3210 for Italy RPT250           RST200 for USA and UK
 051        049           177                      051

Item No. and destination of the specifications which include two pieces of Space gasket No. 5103502801
EH450 except USA EH490V      EH561     EH620  EH760     HT2045D HT2049D HT2062E
      141        136, 140 143, 152/E02 137 140, 176/E32   141   136, 140  137

HT2256D for Australia and France HT2256D except Australia and France HT2276E for Australia and France
          143, 152                             137                             140, 176

HT2276E except Australia and France
            140, E32


Implementation
Already implemented since November, 2002 production
