Image preview - the first page of the document
Y04541-WW-1


>> Download Y04541-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                Change of Carburetor
                                                                                                             Y04541

For Models             RBL250, PB250
Country                RBC250: Brazil, Austria, Italy, France, Netherlands, Spain, UK, Bhutan
                       PB250: France, Spain, Australia
Description            Carburetor has been changed to comply with EU gas emission control.
                       The new carburetor is the same as the specifications for Canada and USA.

Interchangeability(I/C)
Item No.       Current part            Q'ty I/C       New part               Q'ty                  Note
           Carburetor                             Carburetor
    068                                 1     Yes                              1
           5256003000                             5256013000
           Jet                                    Jet                               A component part
    075                                 1     No                               1    of carburetor
           5236046030                             5256013010                                           Jet, plug and throttle
           Plug                                                                     A component part   valve ass'y are the
    070                                 1     No                                    of carburetor
           5206008110                                                                                  component parts of
                                                                                                       new carburetor.)
           Throttle Valve Ass'y                                                     A component part
    072                                 1     No                                    of carburetor
           5236047022

Implementation
Already implemented from December, 2004 production.
