Image preview - the first page of the document
Y04545-WW-1


>> Download Y04545-WW-1 documenatation <<

Text preview - extract from the document
T
ECHNICAL INFORMATION
Subject               Modification of Ignition Coil
                                                                                                           Y04545
                                                                                                             July, 2005


For Models            See below.
Country               See below.

Description           Ignition coil has been modified as shown below.


                                                      Current                                    New
                                                 Vertical oval hole                      Horizontal oval hole
                                      Thickness of lamination: 8.5mm(11/32") Thickness of lamination: 6mm(1/4")

                                       Part No. of Ignition coil: 5927001010    Part No. of Ignition coil: 5927012010




                                                       Current                                   New
                                                   Vertical oval hole                    Horizontal oval hole
                                         Part No. of Ignition coil: 5937001010 Part No. of Ignition coil: 5937001011



Interchangeability(I/C)
 Item No.       Current part              Q'ty I/C        New part                  Q'ty              Note
           Ignition Coil                             Ignition Coil
See below.                                   1   Yes                                 1             See below.
           5927001010                                5927012010
           Ignition Coil                             Ignition Coil
See below.                                   1   Yes                                 1             See below.
           5937001010                                5937001011

Item No. and Destination of Part No. 5927012010
     Model       Item No.                                  Destination
   EM4250           186
                          Canada, USA, Argentina, Austria, France, Italy, Netherlands, Spain, UK, Australia
   EM4251           184
BCX2500, BCX2510    186   Germany
     MS251.4              184      Canada, USA, Spain, Australia
     MS250.4              186      Countries in which MS250.4 have been imported.

Item No. and Destination of Part No. 5937001011
             Model                   Item No.                                Destination
            EM4340L                     186   Austria, France, Italy, Netherlands, Spain, UK
            EM4340                      186   Austria, France, Italy, Netherlands, Spain, UK, New Caledonia, Tahiti
            EM4341                      186   Austria, France, Italy, Netherlands, Spain, UK
      BCX3400, BCX3410                 186       Germany
MS350.4C, MS350.4U, MS351.4U           186       Austria, France, Germany, Italy, Netherlands, Spain, UK
     MS352.4C, MS352.4U                184       Germany

Implementation
Already implemented since February, 2004 production.
