Image preview - the first page of the document
Y04032-WW-1


>> Download Y04032-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject              Change of Fuel Tank Cap and Strap for the diaphragm type of Garden Tools
                                                                                                       Y04032
                                                                                                   (Page 1 of 2)

For Models           See below
Country              All countries
Description          Fuel Tank Cap has been changed.
                     For some models, strap has been also changed.

             Current                                       New




              Fuel Tank Cap                         Fuel Tank Cap
              (5316015000)                          (5256058000)


                    Fuel Tank Cap                            Fuel Tank Cap
                    (5316014000)                             (5256058000)

                            Strap Unit                         Strap Unit
                          (6255021002)                       (5256067000)




Interchangeability(I/C)
All countries except for U.S.A. and Europe:
This change is applied for the following models except for U.S.A. and Europe.
 Item No.     Current part               Q'ty I/C       New part                Q'ty            Note
           Fuel Tank Cap                            Fuel Tank Cap
See below.                                1     Yes                               1
           5316015000                               5256058000

Item No. for 5256058000
 Model      EH561 EH760 HT2256D HT2276E LT250 MS220                  MS221 MS2200      MS2201   MS250 MS251
Item No.     114    111        114        111        057         065            ---     082             065

 Model MS2500 MS2501 MS2800 MS2810 MS3200 MS3210 MS3500 MS3510 MS4200 MS4210 MS5250
Item No. 077   082    033        032       034    085    086    085    086    056

 Model PB250 PE250 RBC220 RBC221 RBC225 RBC226 RBC250 RBC251 RBC255 RBC256 RBC280
Item No. 022  089       065           082            065          082       033

  Model RBC281 RBC320 RBC321 RBC350 RBC351 RBC415 RBC420 RBC421 RBC525 RBE250 RBK250
 Item No.    032        034    085    086    152    085    086    056    089    131

  Model RBL250 RST250
 Item No. 022    057
                                                                                                             Y04032
                                                                                                         (Page 2 of 2)

U.S.A. and European Countries: This change is applies for the following models.
  Item No.        Current part                 Q'ty I/C       New part                    Q'ty          Note
             Fuel Tank Cap Complete                     Fuel Tank Cap
  See below.                                    1    No                                    1
             5316014000                                 5256058000                                 Interchangeable
             Strap Unit                                 Strap                                           as a set
  See below.                                    1    No                                    1
             6255021002                                 5256067000

Item No. for 5256058000 / 5256067000
  Model      EH450       EH561      EH620       EH760      HT2045D HT2062E         HT2256D       HT2276E       LT250
 Item No. 090 / 116    114 / E01 084 / 110     111 / E14 090 / 114     084 / 110   114 / E01     111 / E04     057 / E03

  Model      MS220      MS221     MS250         MS251      MS2500      MS2501      MS2800        MS2800E MS2810
 Item No. 065 / E02    065 / E09 065 / E02     065 / E09   077 / E01   082 / E09   033 / E03     083 / 084 032 / E09

  Model    MS3200 MS3210           MS3500       MS3510     MS4200      MS4200G     MS4210        MS5250
 Item No. 032 / E02 034 / E05      085 / E02   086 / E02    085        116 / E01   086 / E02     056 / 120

  Model PE250 (U.S.A only)         RBC220 RBC221           RBC225 RBC226            RBC250        RBC251 RBC255
 Item No. 089 / E01                065 / E02 065 / E09     082 / E02 082 / E09     065 / E02      065 / E09 082 / E02

  Model RBC256         RBC280 RBC281       RBC320           RBC321     RBC350      RBC351         RBC415       RBC420
 Item No. 082 / E09    033 / E03 032 / E09 032 / E05       034 / E05   085 / E02   086 / E02     152 / E02    085 / E02

  Model RBC421 RBC525 RBE250 (U.S.A. only) RBK250 (European Countries only)                      RST250
 Item No. 086 / E02 056 / 120 089 / E01    131 / E10                                             057 / E03




All Countries: This change is applies for all the following models.
  Item No.       Current part                  Q'ty I/C      New part                    Q'ty           Note
            Fuel Tank Cap Complete                     Fuel Tank Cap
 See below.                                     1   No                                    1
            5316014000                                 5256058000                                  Interchangeable
            Strap Unit                                 Strap                                            as a set
 See below.                                     1   No                                    1
            6255021002                                 5256067000

Item No. for 5256058000 / 5256067000
  Model   MH2556 MS20C            MS3200E MS4200E MS5250E MS5250G          PB250                 PB500R RBC201
 Item No. 077 / 123 066 / 098     083 / 084 116 / 117 123 / 124 074 / 132 022 / E01              026 / 027 066 / 098

  Model   RBC280E RBC320E RBC420E RBC525E RBK525G RBL250                           RBL500         RPT250
 Item No.     083 / 084   116 / 117 123 / 124 074 / 132 022 / E01                  026 / 027      077 / 123


Implementation
Since April 2001 production
