TECHNICAL INFORMATION
Subject                Change of Ignition Coil Assembly
                                                                                                           Y04119


For Models             EW300R, G2400R

Country                All countries

Description            Ignition Coil Assembly has been changed to increase its durability. To distinguish new Ignition
                       Coil Assembly from current one, a letter "A" has been printed at end of production date on
                       Identity Label of new Ignition Coil Assembly.




                                                                             Ignition Coil Assembly
                                       Identity Label






                       Current                                                         New
                               BM37




                                                                                             BM37
                                                                                      A




                                                                                      Letter "A"



Interchangeability(I/C)
Item No.         Current part                Q'ty I/C           New part                    Q'ty          Note
           Ignition Coil Assembly                       Ignition Coil Assembly
See below.                                     1    Yes                                       1
           2277943041                                   2277943051

Item No. of Ignition Coil Assembly
  Model     EW300R G2400R
 Item No.     129         230


Implementation
From Mar. production
