TECHNICAL INFORMATION
Subject               Change of Crankcase Complete
                                                                                                   Y04271


For Models            EW400TR, G5500R
Country               All countries
Description           Crankcase Complete has been changed.
                      The appearance remains the same.



                                                                            Cylinder Head



                                             Gasket                                 Stud



                                                                               Stud

Crankcase Complete

Thread-pitch of threaded hole for the stud

      Current                 New
    1.5 mm (1/16")      1.25 mm (3/64")




Interchangeability(I/C)
  Item No.       Current part                         Q'ty I/C       New part               Q'ty   Note
EW400TR: 072 Crankcase Complete                                Crankcase Complete
                                                       1   Yes                               1
G5500R: 138 2241020101                                         2241020111


Implementation
From September, 2002 production
