Image preview - the first page of the document
Y04314-WW-1


>> Download Y04314-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject               Change of Bush
                                                                                                          Y04314

For Models            MS4150, RBK410
Country               All countries
Description           Hardness of Bush has been changed to assemble it with flexible shaft more easily.




                                                           Bush

                                                                            Current                 New
                                                           Hardness           90                    50
                                      (Flexible shaft)
                                                           Part No.       6111503401           6111503402




Interchangeability(I/C)

Item No.        Current part             Q'ty I/C    New part                   Q'ty               Note
           Bush                                 Bush
    008                                   1 Yes                                    1
           6111503401                           6111503402

 Implementation
Already implemented since Feb., 2003 production.
