TECHNICAL INFORMATION
Subject            Change of Muffler Gasket
                                                                                                      Y04378


For Models         MS3500, MS3500K, MS3510, MS4100, MS4150, MS4200, MS4200E, MS4200G, MS4200K,
                   MS4210, RBC350, RBC350E, RBC351, RBC410, RBC411, RBC420, RBC420E, RBC421,
                   RBK350, RBK410, RBK411, RBK420, RBK420G
Country            All countries
Description        Muffler gasket has been changed as illustrated below. The material remains the same.


                                    Current                                    New




           Thickness                  1.2 mm                                   1.0 mm
           Part No.                5323500200                               5323500600



Interchangeability(I/C)
Item No.    Current part              Q'ty I/C          New part                 Q'ty             Note
   See Muffler Gasket                            Muffler Gasket
                                        1    Yes                                   1
 below. 5323500200                               5323500600

Item No. of Muffler Gasket
   Model MS3500 MS3500K MS3510              MS4100    MS4150     MS4200 MS4200E MS4200G MS4200K
 Item No.    062        096 063              102       131        062     083     092     096
   Model MS4210        RBC350 RBC350E RBC351 RBC410 RBC411                  RBC420 RBC420E RBC421
 Item No. 063           062     083    063    102    107                     062     083    063
   Model RBK350 RBK410 RBK411               RBK420 RBK420G
 Item No.  096    131    088                  096    092


Implementation
Since November 2002 production
