Image preview - the first page of the document
Z4358-WW-1


>> Download Z4358-WW-1 documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION
Subject                 Addition of Gear Assembly and Clutch Assembly
                                                                                                               Z4358


For Models              BFL080F, BFL120F, BFL121F, BFL200F
Country                 All countries
Description             Gear Assembly and Clutch Assembly have become available for easier replacement.
                        See below for the detail.

    Gear Assembly
    It consists of Gear Case, Motor Bracket and Gear portion.
    (Model Label has been stuck on the Motor Bracket in order to distinguish an applicable Model.)

                                                                   Name & Part No.         For Model
          Model Label                                              Gear Assembly A         BFL080F
                                                                     (125189-4)
                                                                   Gear Assembly B
                                                                                           BFL120F
                                                                     (125190-9)
                                                                   Gear Assembly C         BFL121F
                                                                     (125191-7)
                                                                  Gear Assembly D
                                                                                           BFL200F
                                                                    (125192-5)

    Clutch Assembly
    It consists of Spindle and Clutch portion.
                                   Name & Part No.             For Model         Marking            Fastening Torque
    Marking                       Clutch Assembly A
                                                                BFL080F          Yellow     2 - 8 N.m (17.7 - 70.9 in.lbs)
                                     (125193-3)
                                  Clutch Assembly B
                                                            BFL120F, BFL121F      Blue     5 - 12 N.m (44.3 - 106 in.lbs)
                                     (125194-1)
                                  Clutch Assembly C
                                                                BFL200F           Red      8 - 20 N.m (70.9 - 177 in.lbs)
                                     (125195-9)




Interchangeability(I/C)
Item No.         Current part                    Q'ty I/C          New part                  Q'ty            Note
                                                             Gear Assembly A                   1
    066                                                                                              BFL080F
                                                             125189-4
                                                             Gear Assembly B                   1
    066                                                                                              BFL120F
                                                             125190-9
                                                             Gear Assembly C
    066                                                                                        1     BFL121F
                                                             125191-7
                                                             Gear Assembly D
    066                                                                                        1     BFL200F
                                                             125192-5
                                                             Clutch Assembly A
    067                                                                                        1     BFL080F
                                                             125193-3
                                                             Clutch Assembly B
    067                                                                                        1     BFL120F, BFL121F
                                                             125194-1
                                                             Clutch Assembly C
    067                                                                                        1     BFL200F
                                                             125195-9

Implementation
Ready to receive your order
