Image preview - the first page of the document



>> Download VZ7_Chassis documenatation <<

Text preview - extract from the document

                                              Section 1
                                            Introduction
                                    VZ7 Chassis Model/Features
           FEATURES                 VS-45605    VS-50605      VS-50705   VS-55705    VS-60705     VS-70705
             Chassis                   VZ7        VZ7           VZ7+       VZ7+         VZ7+        VZ7+
          Screen Size                  45"        50"            50"        55"          60"         70"
                       TM
        DiamondShield                Optional   Optional      Included   Included     Included    Included
       Advanced PIP/POP                PIP        PIP         PIP/POP    PIP/POP      PIP/POP     PIP/POP
      Digital Convergence               X          X              X          X            X           X
       Digital Comb Filter            3DYC       3DYC          3DYC       3DYC         3DYC        3DYC
             INPUTS
       Rear A/V & S-Video               2          2             2           2           2            2
      Front A/V & S-Video               1          1             1           1           1            1
  Component Inputs (Y,CR&CB)            1          1             1           1           1            1
           OUTPUTS
         Video Monitor                  1         1              1           1           1            1
    Fixed/Variable Audio R/L            1         1              1           1           1            1
                                                  Table 1-1
A total of six Projection TV Models use one of two         processes an entire video frame. This method pro-
versions of the VZ7 Chassis. Two models use the            duces results far superior than those that only pro-
VZ7 Chassis and four models use the VZ7+ Chassis.          cess two or three lines at a time such as Digital Dy-
Table 1-1 lists the models and some of the main fea-       namic or 2D-Y/C processing.
tures.
                                                           The PIP circuitry features the Picture out of Pic-
The VZ7 Chassis uses some of the latest technolo-          ture feature in VZ7+ Models. The PIP circuitry de-
gies available, including those listed in Figure 1-1.      scription is in Section 7.
  Convergence & Raster Correction
