Image preview - the first page of the document

>> Download HC-1100_HD-1000.part2 documenatation <<

Text preview - extract from the document

                                                                                 DLPTM PROJECTOR
                                                                                 DLP16 CHASSIS



                            These models are RoHS-compliant. Provide
                            servicing referring to "NOTES FOR SERVICING
                            RoHS-COMPLIANT PRODUCTS" described in
                            the service manual.

                                           Pb Solder, Pb Joints, Pb PCA
                                          This product uses lead-free solder
                                          on the circuit boards. For repairing
                                          circuit boards, see "Precautions for
                                          resoldering" in this Service Manual.

Before servicing this chassis, it is important that the service person read the "SAFETY PRECAUTIONS" and "PRODUCT
SAFETY NOTICE" in this service manual.

                               MITSUBISHI ELECTRIC
                      Copyright C 2006 Mitsubishi Electric Corporation All Rights Reserved.
Follow the notes and instructions below when servicing RoHS-compliant
  1. For RoHS-compliant products, be sure to use RoHS-compliant service parts.
  2. Check the presence of  marking on the rating plate to distinguish RoHS-
     compliant product from non-RoHS-compliant product.

            With  marking: RoHS-compliant product
            Without  marking: Non-RoHS-compliant product


                                                                             Mark position

  3.   Labels of RoHS-compliant service parts bear  marking for identification

                      Parts Name

                      Parts No.
                                                             Mark position

                                   Model Name   E05R

  4.   Don't use non-RoHS-compliant parts with RoHS-compliant products.
  5.   Service parts for RoHS-compliant products are listed in the parts catalog
       contained in the service manual.
