>> Download HC-1100_HD-1000 documenatation <<Text preview - extract from the document 2006
DLPTM PROJECTOR
DLP16 CHASSIS
MODEL
HC1100/
HD1000
These models are RoHS-compliant. Provide
servicing referring to "NOTES FOR SERVICING
RoHS-COMPLIANT PRODUCTS" described in
the service manual.
Pb Solder, Pb Joints, Pb PCA
This product uses lead-free solder
on the circuit boards. For repairing
circuit boards, see "Precautions for
resoldering" in this Service Manual.
CAUTION
Before servicing this chassis, it is important that the service person read the "SAFETY PRECAUTIONS" and "PRODUCT
SAFETY NOTICE" in this service manual.
MITSUBISHI ELECTRIC
Copyright C 2006 Mitsubishi Electric Corporation All Rights Reserved.
NOTES FOR SERVICING RoHS-COMPLIANT PRODUCTS
Follow the notes and instructions below when servicing RoHS-compliant
products.
1. For RoHS-compliant products, be sure to use RoHS-compliant service parts.
2. Check the presence of marking on the rating plate to distinguish RoHS-
compliant product from non-RoHS-compliant product.
marking
With marking: RoHS-compliant product
Without marking: Non-RoHS-compliant product
Mark position
3. Labels of RoHS-compliant service parts bear marking for identification
purpose.
Parts Name
Parts No.
Mark position
Model Name E05R
4. Don't use non-RoHS-compliant parts with RoHS-compliant products.
5. Service parts for RoHS-compliant products are listed in the parts catalog
contained in the service manual.
-2-
