Image preview - the first page of the document
>> Download PS-5200 & 7200 documenatation <<
Text preview - extract from the document
Service PS5200 /F1N, F2N
PS7200 /F1N, F2N
Manual AV Surround Amplifier
PS5200
AV SURROUND AMPLIFIER PS5200
SURROUND VOLUME
VIDEO SET THX DOLBY PRO LOGIC TAPE 2 MON STEREO RDS EON TP CT L C R
NIGHT 1 2 3 4 5 6 DTS DIGITAL VIRTUAL DSP SOUND TUNED AUTO PTY TA RT SL SC SR
RF AUTO LOCK CIRCLE SURROUND EX MPEG DIRECT MEMORY PRESET SW LFE
ATT
DIGITAL A B
DISPLAY OFF ANALOG MUTE DOWN UP
MLP PCM SLEEP
MUTE
PS5200 / PS7200
7CH INPUT A/D S-DIRECT SLEEP DIMMER
STANDBY
AUX INPUT
POWER ON/STANDBY PHONES TV DVD VCR1 DSS/VCR2 AUX CDR/MD TAPE CD TUNER S-VIDEO VIDEO L AUDIO R
PS7200
AV SURROUND AMPLIFIER PS7200
SURROUND VOLUME
MULTI ROOM
VIDEO SET THX DOLBY PRO LOGIC TAPE 2 MON STEREO RDS EON TP CT L C R
NIGHT 1 2 3 4 5 6 DTS DIGITAL VIRTUAL DSP SOUND TUNED AUTO PTY TA RT SL SC SR
RF AUTO LOCK CIRCLE SURROUND EX MPEG DIRECT MEMORY PRESET SW LFE
ATT
DIGITAL A B
DISPLAY OFF ANALOG MUTE DOWN UP
MLP PCM SLEEP
MULTI ROOM MUTE
A SPEAKERS B 7CH INPUT A/D S-DIRECT SLEEP DIMMER
STANDBY
AUX INPUT
POWER ON/STNDBY PHONES TV DVD VCR1 DSS/VCR2 AUX CDR/MD TAPE CD TUNER S-VIDEO VIDEO L AUDIO R
TABLE OF CONTENTS
1. TECHNICAL SPECIFICATIONS .................................................................................. 1
2. WIRING DIAGRAM ...................................................................................................... 5
3. BLOCK DIAGRAM ........................................................................................................ 7
4. SCHEMATIC DIAGRAM ............................................................................................... 9
5. PARTS LOCATION .................................................................................................... 27
6. IC DATA ..................................................................................................................... 40
7. EXPLODED VIEW AND PARTS LIST ........................................................................ 43
8. ELECTRICAL PARTS LIST ........................................................................................ 50
Please use this service manual with referring to the user guide ( D.F.U. ) without fail.
R
Printed on 100% Recycled Paper
PS5200 / PS7200
341W855010 MIT
Printed in Japan First Issue 2002.02
MARANTZ DESIGN AND SERVICE
Using superior design and selected high grade components, MARANTZ company has created the ultimate in stereo sound.
Only original MARANTZ parts can insure that your MARANTZ product will continue to perform to the specifications for which
it is famous.
Parts for your MARANTZ equipment are generally available to our National Marantz Subsidiary or Agent.
ORDERING PARTS :
Parts can be ordered either by mail or by Fax.. In both cases, the correct part number has to be specified.
The following information must be supplied to eliminate delays in processing your order :
1. Complete address
2. Complete part numbers and quantities required
3. Description of parts
4. Model number for which part is required
5. Way of shipment
6. Signature : any order form or Fax. must be signed, otherwise such part order will be considered as null and void.
USA EUROPE / TRADING BRAZIL
MARANTZ AMERICA, INC MARANTZ EUROPE B.V. PHILIPS DA AMAZONIA IND. ELET. ITDA
1100 MAPLEWOOD DRIVE P. O. BOX 8744, BUILDING SILVERPOINT CENTRO DE INFORMACOES AO
ITASCA, IL. 60143 BEEMDSTRAAT 11, 5653 MA EINDHOVEN CEP 04698-970
USA THE NETHERLANDS SAO PAULO, SP, BRAZIL
PHONE : 630 - 741 - 0300 PHONE : +31 - 40 - 2507844 PHONE : 0800 - 123123 (Discagem Direta Gratuita)
FAX : 630 - 741 - 0301 FAX : +31 - 40 - 2507860 FAX : +55 11 534. 8988
AMERICAS AUSTRALIA CANADA
SUPERSCOPE TECHNOLOGIES, INC. TECHNICAL AUDIO GROUP PTY, LTD LENBROOK INDUSTRIES LIMITED
MARANTZ PROFESSIONAL PRODUCTS 558 DARLING STREET, 633 GRANITE COURT,
2640 WHITE OAK CIRCLE, SUITE A BALMAIN, NSW 2041, PICKERING, ONTARIO L1W 3K1
AURORA, ILLINOIS 60504 USA AUSTRALIA CANADA
PHONE : 630 - 820 - 4800 PHONE : 61 - 2 - 9810 - 5300 PHONE : 905 - 831 - 6333
FAX : 630 - 820 - 8103 FAX : 61 - 2 - 9810 - 5355 FAX : 905 - 831 - 6936
AUSTRALIA THAILAND SINGAPORE
QualiFi Pty Ltd, MRZ STANDARD CO., LTD WO KEE HONG DISTRIBUTION PTE LTD
24 LIONEL ROAD, 746 - 754 MAHACHAI ROAD., 130 JOO SENG ROAD
MT. WAVERLEY VIC 3149 WANGBURAPAPIROM, PHRANAKORN, #03-02 OLIVINE BUILDING
AUSTRALIA BANGKOK, 10200 THAILAND SINGAPORE 368357
PHONE : +61 - (0)3 - 9543 - 1522 PHONE : +66 - 2 - 222 9181 PHONE : +65 858 5535 / +65 381 8621
FAX : +61 - (0)3 - 9543 - 3677 FAX : +66 - 2 - 224 6795 FAX : +65 858 6078
NEW ZEALAND TAIWAN MALAYSIA
WILDASH AUDIO SYSTEMS NZ PAI- YUING CO., LTD. WO KEE HONG ELECTRONICS SDN. BHD.
14 MALVERN ROAD MT ALBERT 6 TH FL NO, 148 SUNG KIANG ROAD, SUITE 8.1, LEVEL 8, MENARA GENESIS,
AUCKLAND NEW ZEALAND TAIPEI, 10429, TAIWAN R.O.C. NO. 33, JALAN SULTAN ISMAIL,
PHONE : +64 - 9 - 8451958 PHONE : +886 - 2 - 25221304 50250 KUALA LUMPUR, MALAYSIA
FAX : +64 - 9 - 8463554 FAX : +886 - 2 - 25630415 PHONE : +60 3 - 2457677
FAX : +60 3 - 2458180
JAPAN Technical KOREA
MARANTZ JAPAN, INC. MK ENTERPRISES LTD.
35- 1, 7- CHOME, SAGAMIONO ROOM 604/605, ELECTRO-OFFICETEL, 16-58,
SAGAMIHARA - SHI, KANAGAWA 3GA, HANGANG-RO, YONGSAN-KU, SEOUL
JAPAN 228-8505 KOREA
PHONE : +81 42 748 1013 PHONE : +822 - 3232 - 155
FAX : +81 42 741 9190 FAX : +822 - 3232 - 154
SHOCK, FIRE HAZARD SERVICE TEST :
CAUTION : After servicing this appliance and prior to returning to customer, measure the resistance between either primary AC
cord connector pins ( with unit NOT connected to AC mains and its Power switch ON ), and the face or Front Panel of product and
controls and chassis bottom.
Any resistance measurement less than 1 Megohms should cause unit to be repaired or corrected before AC power is applied, and
verified before it is return to the user/customer.
Ref. UL Standard No. 1492.
In case of difficulties, do not hesitate to contact the Technical
Department at above mentioned address.
020110MIT
1. TECHNICAL SPECIFICATIONS
PS5200 PS7200
AMPLIFIER SECTION AMPLIFIER SECTION
Maximum Power Output (6 ohms / EIAJ) Maximum Power Output (6 ohms / EIAJ)
Front .................................................................................... 135W Front .................................................................................... 160W
Center .................................................................................. 135W Center .................................................................................. 160W
Surround .............................................................................. 135W Surround .............................................................................. 160W
Continuous Power Output (8 ohms / 20 Hz - 20 kHz) Continuous Power Output (8 ohms / 20 Hz - 20 kHz)
Front ...................................................................................... 90 W Front .................................................................................... 110W
Center .................................................................................... 90 W Center .................................................................................. 110W
Surround ................................................................................ 90 W Surround .............................................................................. 110W
THD Front (20 Hz - 20 kHz) .................................. 8 ohms 0.05 % THD Front (20 Hz - 20 kHz) .................................. 8 ohms 0.05 %
Input Sensitivity/Impedance Input Sensitivity/Impedance
Linear .............................................................. 340 mV/ 47 kohms Linear ............................................................. 340 mV / 47 kohms
Signal to Noise Ratio Signal to Noise Ratio
Linear ................................................................................ 105 dB Linear ................................................................................ 105 dB
DECORDER SECTION DECORDER SECTION
Applicable Signal Format .............................................................. Applicable Signal Format ..............................................................
......................... PCM Audio (fs=32kHz, 44.1kHz, 48kHz, 96kHz), ......................... PCM Audio (fs=32kHz, 44.1kHz, 48kHz, 96kHz),
.................................................... Dolby Digital, DTS, Mpeg2 AAC .................................................... Dolby Digital, DTS, Mpeg2 AAC
Frequency Range Frequency Range
(Analog Input / Sourse Direct) ........... 8 Hz - 100 kHz (◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
