Image preview - the first page of the document
8031040wone


>> Download 8031040wone documenatation <<

Text preview - extract from the document
IV PM-Related

   1. PM Items & Intervals


   2. Handling of IU
1. PM Items & Intervals
Major Item                 MB 7831                              Remarks
Imaging Unit (CMY)         52K                                  Increase of Thickness of the Photo-
                                                                conductive Layer
Imaging Unit (K)           82K                                  2-component Magnetic Brush System:
                                                                Non- contact development with Magnetic
                                                                Blade
Fusing Unit                152K                                 Surface layer of the Roller: Silicon type
                                                                >> PFA (fluorine type)
Paper Dust Remover         152K
Transfer Roller Unit       152K                                 Electronic-conductive Type >> Ion -
                                                                conductive Type
Ozone Filter               152K                                 No. of Cells: 700 >> 1000, Capability of
                                                                Removal increased, Life prolonged
Waste Toner Bottle         30K Equivalent*                      * With Polymerized toner


Toner Cartridge            10K Equivalent*

Filter                     10K                                  Newly added

 -Measurement Conditions: A4C, B/W or C/W Ratio 5%
     Mode: >> C&Bk: 3P/J
 Counter reading for the end of life may be shorter, if the product operating conditions are different
 from those shown here or due to the differences in the ratio between the full color and
 monochrome copies.
2. Handling of IU
                        Tape
 1            2                3




 4-1              4-2          5




OK
