Image preview - the first page of the document



>> Download 8031052wone documenatation <<

Text preview - extract from the document

4. PIC Section
 PIC: Print Image Control


                            1. LED Print Head (LPH)


                            2. LED Gradation Reproduction System


                            3. Outline of the PIC Section


                            4. PIC Image Processing Flow


                            5. Color Shift Correction System
4.1 LED Print Head (LPH)
                                                  LED Unit
                     Perspective View




                                                          Side View
              SLA (SELFOC Lens Array)




                                              LED Chip
                                              (600 dpi = approx. 7,700 chips)


                              Circuit Board

                   LED Chip
 Positioning Pin
4.1.1 Features of LED Print Head
(Similar to 7920)

Advantages
