Image preview - the first page of the document



>> Download pk131wone documenatation <<

Text preview - extract from the document

PK-131 Punch unit for FS-231
                  Specifications
                  Number of holes   2 or 3 holes (Select from the panel): Inch area
                                    4 holes: Metric area
                  Diameter          2 or 3-hole: 8 mm
                                    4-hole: 6.5 mm
                  Paper size        2-hole: 8-1/2
