Image preview - the first page of the document



>> Download Di3010 PC documenatation <<

Text preview - extract from the document

Di3010/Di3010f


           4031
                                                                                                                                                      Parts Catalog
                    PREFACE

1.   The part numbers listed in Parts Catalog are those which were assigned to the parts making up the machine at the time machine was originally intro-
     duced onto the market.


2.   Parts whose INDEX numbers are shown white against a black background in the illustration are those to be used in only certain market areas. These part
     numbers are given in the lower half part of the list section. Check the SFIX No. listed in SFIX CHART on page II to find which part number is applicable to
     your own area.


3.   Parts whose INDEX numbers are shown black against a white background in the illustration are those to be used in all market areas. These parts are
     listed on the upper half part of the list section.


4.   If "NS" follows a part number given in the list section, it indicates that we do not keep a stock of the part. The part is not required for ordinary service jobs,
     either.


5.   If "RP" is shown in the REC column of the list section, it indicates that the part is functionally important.


6.   In the exploded views in this Parts Catalog the parts (Screws & Washes, etc...) which are indicated with a "four-digit" numbers are listed in numerical
     order in the section "SCREWS AND WASHERS". Please check these "four-digit" numbers with the part numbers ("ten-digit" numbers) which should be
     used for ordering the part.


7.   All part numbers consist of "ten-digit" which should all be quoted when ordering a part. The price of parts can be obtained by referring to the "Parts Price
     List" which is separately issued.


8.   All infomation contained in this Parts Catalog is subject to change.




                                                                                                                                                                          I
                                                                                                                                        II
                                                                                                                        Parts Catalog
                   SFIX CHART
                                          FREQUENCY                                                           FREQUENCY
SFIX No.        COUNTRY        VOLTAGE                PAPER SIZE   SFIX No.        COUNTRY         VOLTAGE                 PAPER SIZE
                                             (Hz)                                                                (Hz)
  001      JAPAN FAX            100V        50/60      METRIC        216      CHINA COPIER         220-240V     50/60       METRIC
                                                                              USA/CANADA L AMER-
  011      JAPAN COPIER         100V        50/60      METRIC        301                           120-127V      60          INCH
                                                                              ICA FAX
  202      THIRD AREA FAX      220-240V     50/60      METRIC        307      FEDERAL GOVERNMENT   120-127V      60          INCH
                                                                              USA/CANADA L AMER-
  206      CHINA FAX           220-240V     50/60      METRIC        311                           120-127V      60          INCH
                                                                              ICA COPIER
  211      EUROPE COPIER       220-240V     50/60      METRIC        314      S ARABIA/BRAZIL      120-127V      60         METRIC
  212      THIRD AREA COPIER   220-240V     50/60      METRIC
                                                                                                                                            Parts Catalog
                   CONTENTS

 1.   HOUSING (A)
