Image preview - the first page of the document
>> Download 1155007C documenatation <<
Text preview - extract from the document
MINOLTA CO., LTD., SERVICE ENGINEERING DIVISION
PAGE NO. : 1/1
SERVICE BULLETIN
PROBLEM FUNCTION SAFETY
SERVICEABILITY OTHERS
MODEL NAME : Di620 OTHERS PERFORMANCE CORRECTION
SAFETY REGULATION OTHERS
MODEL CODE : 1155
NO. : 007C
DATE : 980723
SUBJECT : CB LABEL ADDITION
In order to find the Circuit Breaker easily, a Label (01, 02) has been added.
01
1155-2415-02
02
1155-2415-02
BEFORE MODI. AFTER MODI. QTY
NO. F-IND PART NO. PART NO. F-IND PART NAME I SE/NO. AREA
01 1061-7350-01 37-38AA LABEL CB1 1 Y 001036 0524
02 0953-7401-01 37-38BA LABEL CB2 CB1 1 Y 001111 2612
PCJ-242iA PRINTED IN JAPAN
