Image preview - the first page of the document
>> Download 1155008 documenatation <<
Text preview - extract from the document
MINOLTA CO., LTD., SERVICE ENGINEERING DIVISION
PAGE NO. : 1/1
SERVICE BULLETIN
PROBLEM FUNCTION SAFETY
SERVICEABILITY OTHERS
MODEL NAME : Di620 OTHERS PERFORMANCE CORRECTION
SAFETY REGULATION OTHERS
MODEL CODE : 1155
NO. : 008
DATE : 980924
SUBJECT : SOFTWARE PROGRAM OF IC ON PWB-W CHANGE
In the software program of IC2W (01) and IC3W (02) on P.W. Board-W, the unused portion of the program
concerning the communication with Pi6000 has been discontinued. This modification does not affect the function.
02
01
01
1155-IC2W 1155-IC2W
6618-02 6618-03
90G000-00 90G002-00
02
1155-IC3W 1155-IC3W
6619-02 6619-03
90G000-00 90G002-00
BEFORE MODI. AFTER MODI. QTY
NO. F-IND PART NO. PART NO. F-IND PART NAME I SE/NO. AREA
01 36-63AA 1155-6618-02 1155-6618-03 36-63AB IC 1 1 Y 000856 0000
02 36-62AA 1155-6619-02 1155-6619-03 36-62AB IC 1 1 Y 000856 0000
