Image preview - the first page of the document
>> Download 1155001 documenatation <<
Text preview - extract from the document
MINOLTA CO., LTD., SERVICE ENGINEERING DIVISION
PAGE NO. : 1/4
SERVICE BULLETIN
PROBLEM FUNCTION SAFETY
SERVICEABILITY OTHERS
MODEL NAME : Di620 OTHERS PERFORMANCE CORRECTION
SAFETY REGULATION OTHERS
MODEL CODE : 1155
NO. : 001
DATE : 980508
SUBJECT : CORRECTION OF SERVICE MANUAL
Please amend your Service Manual according to the instructions given below.
Page: M-4
CORRECT: Transports
Page: M-16
CORRECT: -653V
Page: M-55
CORRECT: Doctor Blade
CORRECT: Developer Regulator
PCJ-242i PRINTED IN JAPAN
S/B NO. : 1155-001 PAGE NO. : 2/4
Page: M-58
CORRECT: 4.5%
CORRECT: TARGET T/C LEVEL
Page: M-59
DELETE
CORRECT: T/C drops below 3%
Page: G-7
DELETE
PCJ-247i PRINTED IN JAPAN
S/B NO. : 1155-001 PAGE NO. : 3/4
Page: T-8
CORRECT: EDH take-up
EDH turnover/exit
EDH transport
Page: T-87
CORRECT: 400K
DELETE
CORRECT: 3
CORRECT: 4
PCJ-247i PRINTED IN JAPAN
S/B NO. : 1155-001 PAGE NO. : 4/4
Page: S-17
CORRECT:
PCJ-247i PRINTED IN JAPAN
