Image preview - the first page of the document



>> Download 1155028 documenatation <<

Text preview - extract from the document

                                                                MINOLTA CO., LTD., SERVICE ENGINEERING DIVISION
                                                                                                       PAGE NO. : 1/1
                  SERVICE BULLETIN
                                                                 PROBLEM           FUNCTION                    SAFETY

                                                                                 SERVICEABILITY                OTHERS

 MODEL NAME :     Di620                                           OTHERS         PERFORMANCE              CORRECTION

                                                                               SAFETY REGULATION               OTHERS
 MODEL CODE :     1155
          NO. :   028
         DATE :   990205
      SUBJECT :   POLYESTER FILM ADDED



 The edge of the film is affixed to the pre-image transfer guide plate by adhesive. Now, to increase production
 efficiency, the adhesive has been discontinued and a polyester film (01) has been affixed instead.




                                                                                  Film



         Pre-Image Transfer
                Guide Plate




                                                                  01




           BEFORE MODI.               AFTER MODI.                                       QTY
NO.    F-IND        PART NO.       PART NO.         F-IND         PART NAME                       I   SE/NO.     AREA


01                              1155-4110-01    23-45AA     POLYESTER FILM                  1 Y 005441           0000
