Image preview - the first page of the document



>> Download 1155029 documenatation <<

Text preview - extract from the document

                                                                  MINOLTA CO., LTD., SERVICE ENGINEERING DIVISION
                                                                                                         PAGE NO. : 1/1
                  SERVICE BULLETIN
                                                                   PROBLEM           FUNCTION                    SAFETY

                                                                                   SERVICEABILITY                OTHERS

 MODEL NAME :     Di620                                             OTHERS         PERFORMANCE              CORRECTION

                                                                                 SAFETY REGULATION               OTHERS
 MODEL CODE :     1155
          NO. :   029
         DATE :   990310
      SUBJECT :   BUSHING CHANGE



 The material for bushing A (01) has been changed from plastic to metal. This prevents noise from occurring due to
 vibration while the copier is being driven.

 The material for bushing B (02) has not been changed because bushing B (02) is not affected by vibration.




                                                                                  02


                  01




           BEFORE MODI.                 AFTER MODI.                                       QTY
NO.    F-IND        PART NO.        PART NO.          F-IND         PART NAME                       I   SE/NO.     AREA


01                               1274-2611-01     08-45AA     BUSHING                           1 Y 006110         0000

02    08-12AA     1200-3121-07   1200-3121-07     08-12AB     BUSHING                    2      1 - 006110         0000
