                                                              MINOLTA CO., LTD., SERVICE ENGINEERING DIVISION
                                                                                                PAGE NO. : 1/2
                SERVICE BULLETIN
                                                               PROBLEM          FUNCTION             SAFETY

                                                                              SERVICEABILITY         OTHERS

MODEL NAME :    Di620                                          OTHERS         PERFORMANCE          CORRECTION

                                                                            SAFETY REGULATION        OTHERS
MODEL CODE :    1155
        NO. :   035
      DATE :    990602
   SUBJECT :    CHANGE OF CABLE MOUNTING BRACKET


PROBLEM: The Cable Mounting Bracket (02) installed on the Scanner Assy (01) can at times be broken.
CAUSE: When the Scanner is moved, the Scanner Drive Cable interferes with the Cable Mounting Bracket (02),
       causing the Cable Mounting Bracket (02) to wear.
SOLUTION: The following changes have been made to increase the strength of the Cable Mounting Bracket (02).
          -The shape of the Cable Mounting Bracket (02) has been changed.
          -A Screw hole has been made in the Scanner Assy (01).
          -As a result of the change made in the shape of the Cable Mounting Bracket (02), a tapping screw
           (9735-0306-13) has been added.




                                    02


                                                  01



  View from Arrow

                               01                                                01




                                         02                                                02




                                                       Hole Added


                         Scanner Drive Cable                                   Scanner Drive Cable
                                                                                       9735-0306-13
                                                                                       (1 piece added)




                                                                                   PCJ-242iA PRINTED IN JAPAN
  S/B NO. :   1155-035                                                                              PAGE NO. : 2/2




 NOTE: The new Bracket (02) must be installed in premodification machines with the new 1st Slider (01).


              BEFORE MODI.             AFTER MODI.                                     QTY
NO.    F-IND         PART NO.       PART NO.         F-IND         PART NAME                   I   SE/NO.   AREA


01    12-17AA      1155-0152-01   1155-0152-02   12-17AB     1ST SLIDER               1      1 Y 009409     0000

02    12-10AA      1155-1411-02   1155-1411-03   12-10AB     BRACKET                  1      1 S 009409     0000




                                                                                      PCJ-247iA PRINTED IN JAPAN
