Image preview - the first page of the document



>> Download 1155038 documenatation <<

Text preview - extract from the document

                                                                        MINOLTA CO., LTD., SERVICE ENGINEERING DIVISION
                                                                                                               PAGE NO. : 1/1
                     SERVICE BULLETIN
                                                                        PROBLEM            FUNCTION                    SAFETY

                                                                                         SERVICEABILITY                OTHERS

 MODEL NAME :        Di620                                               OTHERS          PERFORMANCE              CORRECTION

                                                                                       SAFETY REGULATION               OTHERS
 MODEL CODE :        1155
             NO. :   038
         DATE :      990714
      SUBJECT :      C0110 DISPLAY


 PROBLEM: There is a possibility that malfunction "C0110" may at times occur due to the malfunctioning corona wire
           cleaning mechanism of the image transfer/paper separator coronas unit (01).
 CAUSE: The corona wire cleaner moves back and forth on the corona wire, controlled as detailed below. If,
        however, there are variations in the accuracy of parts of the image transfer/paper separator coronas unit
        (01), the cleaner reaches the very end of the screw of the transport shaft (02) and goes beyond the screw
        part before 11.6 sec. elapse after the cleaning motor (M8) has started turning forward.
 SOLUTION: The screw part of the transport shaft (02) has been made longer to give allowance for the cleaner
            motion.




        01
                                  Paper separator wire
                                    Image transfer
                                    corona wire                    02

                                                                                     Screw part




       Cleaner

                       02
                                                                          355.2mm360.1mm                  16.9mm12mm


                                          Cleaning motor (M8)

             BEFORE MODI.                    AFTER MODI.                                        QTY
NO.    F-IND           PART NO.          PART NO.          F-IND         PART NAME                        I   SE/NO.     AREA


01    24-35AA        1155-0357-01      1155-0357-03      24-35AB   TRANS/SEP CORONA            1      1 Y 255736         0000

02    24-26AA        1075-4161-02      1075-4161-03      24-26AB   CONVEYOR SHAFT              1      1 Y 255736         0000




                                                                                              PCJ-242iA PRINTED IN JAPAN
