Image preview - the first page of the document
>> Download 01-rh20-genl documenatation <<
Text preview - extract from the document
Customer Care Solutions
RH-20 Series Transceivers
General Information
Issue 1 10/2003 Company Confidential Nokia Corpora-
RH-20 Company confidential
General Information CCS Technical Documentation
Table of Contents
Page No
RH-20 Product Selection ...............................................................................................3
Accessories List .............................................................................................................4
Technical Specifications ................................................................................................6
General Specifications of Transceiver RH-20 .............................................................6
Battery endurance ......................................................................................................6
Environmental conditions .........................................................................................7
Transceiver Features ....................................................................................................8
Electrical Characteristics .............................................................................................9
Page 2 Nokia Corporation. Issue 1 10/2003
Company confidential RH-20
CCS Technical Documentation General Information
RH-20 Product Selection
The RH-20 is a Triple Band transceiver unit designed for the EGSM900, GSM1800 and
GSM1900 (EDGE) networks. It is a GSM900 phase 2 power class 4 transceiver (2W) and a
GSM1800/1900 power class 1 (1W) transceiver. It is also an EDGE900 power class E2
(0.5W/27dBm) and an EDGE1800/1900 power class E2 (0.4W/26dBm) transceiver. The
products share the 1AO radio module and differ in details on mechanics. Refer to the
diagrams on the following pages.
RH-20 Product and modules
Material code/
Name Type code Module code
module type
Basic transceiver RH-20 0504790
Radio module 1AO 0202020
UI board 1dm 0202023
Mechanics assembly parts 0262937
Software module ( basic SW ) On Flash memory
Figure 1: RH-20 transceiver
Issue 1 10/2003 Nokia Corporation. Page 3
RH-20 Company confidential
General Information CCS Technical Documentation
Accessories List
Batteries Product code:
Battery BLD-3 780mAH Li-Ion 0670334
Chargers Product code:
AC Travel Charger ACP-7E (EUR) 207-253 Vac 0675144
AC Travel Charger ACP-7U (US) 108-132 Vac 0675143
AC Travel Charger ACP-7C (China) 198-242 Vac 0675158
AC Travel Charger ACP-7X (UK) 207-253 Vac 0675145
AC Travel Charger ACP-7H (Hong Kong) 180-220 Vac 0675146
AC Travel Charger ACP-7A (AUS) 216-264 Vac 0675148
Performance Travel Charger ACP-8E (EUR) 90-264 Vac 0675195
Performance Travel Charger ACP-8K (Korea) 90-264 Vac 0675199
Performance Travel Charger ACP-8X (UK) 90-264 Vac 0675197
Performance Travel Charger ACP-8U (US) 90-264 Vac 0675196
Performance Travel Charger ACP-8C (China) 90-264 Vac 0675211
Performance Travel Charger ACP-8A (Australia) 90-264 Vac 0675214
Performance Travel Charger ACP-9E (EUR) 0675149
Performance Travel Charger ACP-9U (US) 0675151
Performance Travel Charger ACP-9X (UK) 0675150
Performance Travel Charger ACP-9A (AUS) 0675152
Performance Travel Charger ACP-9J (Japan) 0675153
Performance Travel Charger ACP-9UR (US) 0675159
Performance Travel Charger ACP-9UJ (Brazil) 0675169
Performance Travel Charger ACP-9C 0675204
Performance Travel Charger ACP-9UB 0675224
Performance Travel Charger ACP-9G (Brazil) 0675225
ACP-12E Travel Charger (EUR) 90-264 Vac 0675294
ACP-12X Travel Charger (UK) 90-264 Vac 0675296
ACP-12U Travel Charger (US) 90-264 Vac 0675303
ACP-12UB Travel Charger (Brazil) 90-264 Vac 0675203
ACP-12G Travel Charger (US) 90-264 Vac 0675295
ACP-12C Travel Charger (China) 90-264 Vac 0675297
ACP-12A Travel Charger (Australia) 90-264 Vac 0675300
Page 4 Nokia Corporation. Issue 1 10/2003
Company confidential RH-20
CCS Technical Documentation General Information
ACP-12AR Travel Charger (Argentina) 90-264 Vac 0675298
Portable and Office Accessories Product code:
Stereo Headset HDS-3 0694093
Inductive Loopset LPS-4 0630443
Cigarette Lighter Charger LCH-12 0675120
Battery Charging stand DDC-1 0675243
Connectivity Desk Stand DCV-14 0675323
Connectivity Adapter Cable DKU-5 0730235
Music Stand DT-1 0694119
TTY-Adapter HDA-10
Camera Headset HS-1C 0694124
Mobile Accessories: Carkit 143 (Americas) Product code:
Handsfree unit HFU-4 0694103
Mobile Holder MBC-15S 0650041
Mounting plate MKU-1 0620036
Handsfree microphone HFM-8 0690016
External HF speaker HFS-12 0629009
System cable SCU-4 0630471
Power cable PCU-4 0630478
Boom headset HDB-4 0694094
Antenna Coupler AXF-15S 0750189
Mobile accessories (not included in Carkit Sales Pack):
Headrest handsfree BHF-1 0694102
Issue 1 10/2003 Nokia Corporation. Page 5
RH-20 Company confidential
General Information CCS Technical Documentation
Technical Specifications
General Specifications of Transceiver RH-20
Dimensions (mm) Weight Volume
Unit
(L x W x T) (g) (cm3)
Transceiver with BLD-3 780mAh Li- 106 x 45 x 17.5 83 68
Ion battery pack
Table 1: Main RF characteristics
Parameter Unit and value
Cellular system EGSM900/GSM1800/GSM1900
RX Frequency range EGSM900: 925 ... 960 MHz
GSM1800: 1805...1880 MHz
GSM1900: 1930...1990 MHz
TX Frequency range EGSM900: 880 ... 915 MHz
GSM1800: 1710 ...1785 MHz
GSM1900: 1850 ...1910 MHz
Duplex spacing EGSM900: 45 MHz
GSM1800: 95 MHz
GSM1900: 80 MHz
Channel spacing 200 kHz
Number of RF channels EGSM900: 174
GSM1800: 374
GSM1900: 300
Output Power EGSM900: GSMK 5...33 dBm
EGSM900: 8-PSK 5...27 dBm
GSM1800: GSMK 0...30 dBm
GSM1800: 8-PSK 0...26 dBm
GSM1900: GSMK 0...30 dBm
GSM1900: 8-PSK 0...26 dBm
Number of power levels GSMK EGSM900: 15
GSM1800: 16
GSM1900: 16
Number of power levels 8-PSK EGSM900: 12
GSM1800: 14
GSM1900: 14
Page 6 Nokia Corporation. Issue 1 10/2003
Company confidential RH-20
CCS Technical Documentation General Information
Battery endurance
Nokia measurements of the operational times in GSM 900/ 1800 are:
Talk time*
Battery : BLD-3 up to 2.5 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
